PCI Board 8-Analog + 32 Digital Output Keithley KPCI-3130

• Simplifies laser diode LIV testing prior to packaging or active temperature control
• Integrated solution for in-process LIV production testing of laser diodes at the chip or bar level
• Sweep can be programmed to stop on optical power limit
• Programmable pulse on time from 500ns to 5ms up to 4% duty cycle
• Pulse capability up to 5A, DC capability up to 1A



• 1 mHz - 165 MHz frequency output range
• 2 channels
• 3 ns - 1000 s pulse width range
• 10 V amplitude into 50 O, 20 V into 1 k O



• 8.5 digit true resolution
• 8k Memory(optional 32k or 128k)
• Exceptional measurement integrity with high speed
• Broad range of built-in measurement functions



• Measures resistances up to 10000TO
• 1fA - 20mA current measurement range
• <20 µV burden voltage on lowest current ranges
• 200 TO input impedance



• 20mA output current without power supply
• 8 analog outputs
• 32 high-current digital I/O lines (user configurable)



• Choose from three sensitive electrometers for precision high resistance and low current measurements.



• USB 2.0 and USB 1.1, true plug-and-play compatibility
• 16 SE/ 8 DI analog input channels
• 16-bit resolution
• High and low programmable gains
• Input/output speeds up to 500kS/s
• Up to 33 digital I/O lines



• 12-bit resolution
• Throughput of up to 400kS/s
• Digital I/O scanning speeds of up to 3MHz
• 16 single-ended or 8 differential analog inputs
• 23 digital I/O lines



• 6.5 digit DMM
• Single-instrument solution for continuity and hi-pot type leakage resistance measurements
• Programmable constant V source (50-500V) supports high speed, high resistance measurements
• Programmable constant I source (0-50mA) with dry circuit clamp helps prevent device stress or damage during low resistance measurements



• 10fA resolution
• 5-1/2 digit resolution
• <200µV burden voltage
• measure currents from 20fA to 20mA
