Power Quality Analyzers | FLUKE

• 2000A AC/DC current
• 600 V CAT IV power analyzer
• Data logging
• Troubleshoot harmonics
• Inrush current



• Power Quality Analyzer Measures power (W, VA, VAR) and power factor (PF, DPF)
• Oscilloscope Dual-channel scope 20 MHz bandwidth
• Multimeter
• Recorder
• Harmonics Up to 51st
• Power One and three phase



• Energy loss calculator
• Real-time analysis of trends using the cursors and zoom tools
• Highest safety rating in the industry
• Measure all three phases and neutral
• Automatic Trending
• Ten power quality parameters on one screen according to EN50160 power quality standard
• Logger function



• Power inverter efficiency: Simultaneously measure AC output power and DC input power
• PowerWave data capture: Capture fast RMS data, show half-cycle and waveforms
• Energy loss calculator
• Troubleshoot real-time
• Highest safety rating in the industry
• Measure all three phases and neutral



• 400 Hz measurement
• Power inverter efficiency: Simultaneously measure AC output power and DC input power
• PowerWave data capture: Capture fast RMS data, show half-cycle and waveforms
• Energy loss calculator
• Troubleshoot real-time
• Highest safety rating in the industry
• Measure all three phases and neutral



• Key measurements: Voltage, current, power, power factor and associated values
• Bright, color touch screen
• Two USB ports
• Compact size: designed to fit in tight spaces and panels.
• Highest safety rating in the industry
• Energy analyze application software

• 70 V to 300 V Operating Voltage
• Fast and easy recording of voltage trends, dropouts, and power quality
• Continuous recording of all values with no gaps
• Flicker recording to EN 61000-4-15, individual harmonic and THD values
• Min, Max, and Average RMS values

• Record power and associated parameters for up to 45 days
• Measure harmonic distortion caused by electronic loads
• Voltage event capture
• View graphs and generate reports



• monitor & logging: V, A, W, VA, VAR, PF, energy, flicker, voltage events, and THD
• Plug and play
• Determines the root cause
• Monitors power for the long-term
• 0.1% voltage accuracy IEC61000-4-30 Class-A compliant
• IP65 water-proof



• monitor & logging: V, A, W, VA, VAR, PF, energy, flicker, voltage events, and THD
• measures voltage & current harmonics, interharmonics, mains signaling, unbalance, frequency
• Plug and play
• Determines the root cause
• Monitors power for the long-term
• 0.1% voltage accuracy IEC61000-4-30 Class-A compliant
• IP65 water-proof



• monitor & logging: V, A, W, VA, VAR, PF, energy, flicker, voltage events, and THD
• measures voltage & current harmonics, interharmonics, mains signaling, unbalance, frequency
• Plug and play
• Determines the root cause
• Monitors power for the long-term
• 0.1% voltage accuracy IEC61000-4-30 Class-A compliant
• five hour UPS
• IP50 advanced protection



• Power quality that meets the standard: comply with IEC61000-4-30 standards for voltage, current, power, harmonics, flicker etc.
• 5 MHz, 8000 Vpk waveform capture: Get a detailed picture of even the shortest events
• 5 MHz Transient Voltage
• Captures everything
• Plug and play
• Wireless connection



• 8 input channels
• Fully IEC 61000-4-30 Class-A standard compliant
• Power quality statistics according to EN50160, DISDIP tables, ITIC, CEBEMA, ANSI
• 10 MHz, 6000 Vpk waveform capture
• GPS time synchronization
• records rms, min, max values for: Voltage Current Power P, Q, S Power Factor kWh Flicker Unbalance Frequency Harmonics Interharmonics



• 1 to 3 power phases
• Bandwidth from dc to 3 MHz / 10 MHz
• FFT analysis, vector diagram, and Digital Oscilloscope
• Voltage, current and power harmonics measured up to the 40th harmonic



• 1 kHz test frequency
• 0.25% accuracy
• test signal level: 2V via 400O source



• 50, 60, 100, 120 Hz, 200 Hz to 20 kHz (100 Hz steps), 100 kHz test frequencies
• 0.1 % basic accuracy (0.05 % for PM 6304C)
• Easy to use, at-a-glance display



• 50, 60, 100, 120 Hz 200 Hz to 100 kHz (100 Hz steps)
• 100 kHz to 1 MHz (1 kHz steps) test frequencies
• 0.1 % basic accuracy
• Easy to use, at-a-glance display



• 3, 4 or 6 power phases
• Bandwidth from dc to 3 MHz / 10 MHz
• FFT analysis, vector diagram, and Digital Oscilloscope
• Voltage, current and power harmonics measured up to the 40th harmonic



• Measure key parameters on direct-on-line motors including torque, RPM, mechanical power and motor efficiency
• Perform dynamic motor analysis by plotting of motor derating factor against load according to NEMA/IEC guidelines
• Calculate mechanical power and efficiency without the need of mechanical sensors, just connect to the input conductors and you're ready to go
• Measure electrical power parameters such as voltage, current, power, apparent power, power factor, harmonic distortion and unbalance to identify characteristics that impact motor efficiency
