Peak Power Meter 1mW..8kW Hameg HM8115-2

• Frequency Range 50mHz…10MHz
• Output Voltage up to 10Vpp (into 50O)
• Waveforms: Sine Wave, Triangle, Square Wave, Pulse, DC



• 70 MHz bandwidth
• 4 analog channels and MSO (Mixed Signal Opt. HO3508) with 8 Logic Channels
• 2 GSa/s sample rate on 2 channels, 1 GSa/s on 4 channels



• Wide Measurement Range 1mW…8kW
• Voltage Range 100mV…500V, Current Range 1mA…16A
• Frequency Range DC…1kHz
• Simultaneous Voltage, Current and Power Display
• Display of apparent, effective and reactive Power
• Power Factor Display



• 50 MHz bandwidth
• 2 analog channels
• Time Base 20ns/div."¦100s/div
• 100MSa/s Real Time Sampling, 2GSa/s Random Sampling
• 2kPts Memory per Channel



• Outstanding Frequency Range 1Hz…3GHz
• Output Power -135…+13dBm
• Frequency Resolution 1Hz (Accuracy 0.5ppm)



• Frequency Range 10µHz…25MHz
• Output Voltage 5mVpp…10Vpp (into 50O) DC Offset ±5mV…5V
• Arbitrary Waveform Generator: 250MSa/s, 14Bit, 256kPts
• Sine, Square, Pulse, Triangle, Ramp, Arbitrary Waveforms incl. Standard Curves (white Noise, Cardiac etc.)



• 3 x 0…32V/0…10A 384W max.
• 384W Output Power realized by intelligent Power Management
• Low Residual Ripple: <150µVrms due to linear Post Regulators
• High Setting- and Read-Back Resolution of 1mV up to 0.2mA



• 350 MHz bandwidth
• 2 analog channels and MSO(Mixed Signal Opt.HO3508 [HO3516]) with 8 [16] Logic Channels
• 2 GSa/s sample rate on each channel, 4 GSa/s on half-channel



• Frequency Range 100kHz…1.6GHz
• Tracking Generator HMS1010 -20…0dBm
• Amplitude Measurement Range -114…+20dBm
• DANL -135dBm with Preamp. Option HO3011
• Sweep Time 20ms…1,000s
• Resolution Bandwidth 100Hz…1MHz in 1-3 Steps, 200kHz (-3dB); additional 200Hz, 9kHz, 120kHz, 1MHz (-6dB)



• Basic Accuracy 0.05 %
• Measurement Functions L, C, R, |Z|, X, |Y|, G, B, D, Q, T, ?, M, N
• Test Frequencies 20Hz…200kHz
• Up to 12 Measurements per Second
• Parallel and Series Mode
