Frequency Range 10µHz�25MHz
Output Voltage 5mVpp�10Vpp (into 50O) DC Offset ±5mV�5V
Arbitrary Waveform Generator: 250MSa/s, 14Bit, 256kPts
Sine, Square, Pulse, Triangle, Ramp, Arbitrary Waveforms incl. Standard Curves (white Noise, Cardiac etc.)
Total harmonic Distortion 0.04% (f <100kHz)
Burst, Sweep, Gating, external Trigger
Rise Time <8ns, in Pulse Mode 8�500ns Variable-Edge-Time
Pulse Mode: Frequency Range 100µHz�12.5MHz [25MHz], Pulse Width 15ns�999s, Resolution 5ns
Modulation Modes AM, FM, PM, PWM, FSK (int. and ext.)
10MHz Timebase: ±1ppm TCXO, rear I/O BNC Connector
Front USB Connector: Save and Recall of Waveforms and Settings
8.9cm (3.5") TFT: crisp Representation of the Waveform and all Parameters
USB/RS-232 Dual-Interface, optional Ethernet/USB or IEEE-488 (GPIB)

Standard accessories

Line cord
Operating manual
CD

Recommended options

HO730 Dual-Interface Ethernet/USB
HO740 Interface IEEE-488 (GPIB), galvanically isolated
HZ13 Interface cable (USB) 1.8 m
HZ14 Interface cable (serial) 1:1
HZ20 Adapter plug BNC plug - 4 mm safety sockets
HZ24 Attenuators 3/6/10 and 20 dB
HZ33 Test cable BNC plug - BNC plug 0.5 m
HZ34 Test cable BNC plug - BNC plug 1.0 m
HZ42 19’’ Rackmount kit 2RU
HZ72 IEEE-488 (GPIB) Cable 2 m
