General Purpose Handheld Multimeter Metrel MD 9020

• Loop impedance / prospective fault current
• Line impedance / prospective short-circuit current
• Built-in fuse characteristics for quick evaluation of measuring results
• RCD tests (trip out time, contact voltage, ramp test, Autotest)
• Testing on 1- and 3-phase systems
• Phase sequence test



• Bidirectional resistance measurement from 0,1 µO up to 2000 O
• test current up to 10 A
• Highly efficient 10 A current source generates 10 A into 200 mO load for 15 min without overheating
• High overvoltage protection (CAT IV / 300 V)
• Custom limits can be set for PASS / FAIL evaluation of test result.
• 50 Hz / 60 Hz ripple detection and rejection.
• Instrument can be powered from mains or internal rechargeable battery.
• Up to 1000 test results with timestamp can be stored in internal memory.
• PC SW HVLink PRO enables downloading, review, analyses and printing of test results.



• DC insulation resistance,
• PE conductor continuity test,
• Line and Loop resistances with Fuse evaluation table built-in,
• RCD test with Trip lock function, phase sequence in 3-phase systems,
• on-line voltage monitor,
• 3-wire Earth resistance test with built-in battery operated generator,
• Leakage Current test,
• test of Luminance with optional LUX meter probe.



• High resolution and accuracy
• 1000V TRMS AC, DC voltage measurement;
• 10A TRMS AC, DC current measurement;
• 60nF..25mF Capacitance measurement;
• 600O..60MO Resistance measurement;
• Diode test;
• 5Hz..1MHz Frequency of digital signals measurement
• Temperature measurement(thermocouple type K included)



• meets overvoltage category CAT IV 1000 V
• TRMS AC, DC voltage measurement;
• TRMS AC, DC current measurement;
• Capacitance measurement;
• Resistance measurement;
• Diode test;
• Frequency measurement;
• Electric field detection;
• Continuity test (acoustic signaling);
• Temperature measurement.



• DC and TRMS AC voltage up to 600 V
• TRMS AC current measurement up to 1000 A
• Resistance measurement
• Continuity test
• Frequency measurement
• Contact temperature measurement
• Power factor
• Power (W, VA, Var)



• Continuity tests (200 mA, 4 A, 10 A, 25 A).
• Insulation resistance.
• Substitute leakage current.
• Differential leakage current.
• Touch leakage current.
• IEC cord polarity test.
• Leakage and load TRMS current measurement with current clamp.



• Voltage: TRMS, peak, crest factor (4-channel)
• Current: TRMS, peak, crest factor (4-channel)
• Power (active, reactive, apparent)
• Power measurements fully compliant with IEEE 1459 (active, nonactive, fundamental, harmonic, load unbalance)
• Unbalance, flicker measurement
• Harmonic and interharmonic analysis up to 50th harmonics, THD measurement
• Energy (active, reactive, generated, consumed)
• Power quality analysis according to EN 50160 and IEC 61000-4-30 Class A



• Both IP (inductive) & IG (contact) RPM;
• ms Fuel-injection on time;
• % Duty cycle;
• Dwell angle;
• 1000V TRMS AC, DC voltage measurement;
• 10A TRMS AC, DC current measurement;
• 6uF..2mF Capacitance measurement;
• 600O..60MO Resistance measurement;
• Electric field detection;
• Temperature measurement(thermocouple type K included)



• TRMS AC voltage and current measurement.
• Frequency measurement.
• Power: measures various power parameters (active, reactive, apparent power, THD, PF, phase displacement).
• Intelligent loss analysis: complex algorithms detect loss and allow determining possible reasons for current loss.
• Harmonics: measures current or voltage harmonic components and a percentage value of a harmonic up to the 49th.
• Total Harmonic Distortion (THD)
• Power Factor (PF).
