Multimetru digital portabil industrial Metrel MD 9040

• Five pre-set test voltages: 250V, 500V, 1000V, 2500V and 5000V
• up to 1 T? for insulation resistance
• 600 V for voltage measurements
• Quick setting - Quick & Easy test voltage selection
• Faster testing - 5 mA current source for quick charging of capacitive loads
• Safe - High CAT IV, 600 V voltage protection
• Easy to read - Large, bright LCD display with backlight



• Continuity tests (200 mA, 4 A, 10 A, 25 A).
• Insulation resistance.
• Substitute leakage current.
• Differential leakage current.
• Touch leakage current.
• IEC cord polarity test.
• Leakage and load TRMS current measurement with current clamp.



• Voltage testing up to 1000 V
• Automatic AC/DC recognition
• Continuity buzzer and led to indicate resistances below 500 k?
• Phase & Rotating Field Test
• RCD trip testing
• Diode Test
• Auto Power Off



• Voltage: TRMS, peak, crest factor (4-channel)
• Current: TRMS, peak, crest factor (4-channel)
• Power (active, reactive, apparent)
• Power measurements fully compliant with IEEE 1459 (active, nonactive, fundamental, harmonic, load unbalance)
• Unbalance, flicker measurement
• Harmonic and interharmonic analysis up to 50th harmonics, THD measurement
• Energy (active, reactive, generated, consumed)
• Power quality analysis according to EN 50160 and IEC 61000-4-30 Class A



• Insulation resistance with DC voltage
• Continuity of PE conductors with 200 mA test current with polarity change
• Continuity of PE conductors with 7 mA test current (continuous measurement) without RCD tripping
• Line impedance
• Loop impedance
• Loop impedance with Trip Lock RCD function
• TRMS voltage and frequency
• Phase sequence
• RCD testing (general and selective, type AC, A and B)
• Earth resistance (3-wire method).



• All tests on 3-phase electrical equipment can be carried out, including live leakage test, power, polarity, RCD and Active polarity.
• Simple connection to the PAT/MACHINE tester with automatic detection.
• Simple test procedures, identical to single phase equipment.
• Test sequence for 3-phase tests are automatically set, based on entered test codes and input voltages.



• Bidirectional resistance measurement from 0,1 µO up to 2000 O
• test current up to 10 A
• Highly efficient 10 A current source generates 10 A into 200 mO load for 15 min without overheating
• High overvoltage protection (CAT IV / 300 V)
• Custom limits can be set for PASS / FAIL evaluation of test result.
• 50 Hz / 60 Hz ripple detection and rejection.
• Instrument can be powered from mains or internal rechargeable battery.
• Up to 1000 test results with timestamp can be stored in internal memory.
• PC SW HVLink PRO enables downloading, review, analyses and printing of test results.



• Wiring check
• DC insulation resistance
• Continuity test
• Line and Loop resistance
• RCD test
• Phase sequence
• Pass/Fail visual and audio presentation of results



• Measurement of step voltage and contact voltage.
• Measurement of earthing resistance with resolution of 1 m?.
• Measurement of specific earth resistance.
• High current of up to 50 A and effective suppression of noise
• Excellent immunity even against changing earth currents.
• Autonomous Step Voltage meter: no need for long voltage leads.
• Downloads test results directly to the PC with the help of the professional PC SW package HVLink



• Earth bond / continuity resistance (200 mA)
• Insulation resistance
• Insulation resistance of isolated accessible conductive parts
• Substitute leakage current
• Substitute leakage current of isolated accessible conductive parts
• Differential leakage current
• Touch leakage current
• IEC cord polarity test
