Tester instalatii electrice electrician Metrel MI 2150 INSTALLCHECK

• easy to use LAN tester with wide variety of functions for fault finding
• troubleshooting on IT cabling connections
• TDR facility with adjustable NVP
• determination of distance to the fault
• cable length measurement
• pair determination in multi-pair cables
• crossed pairs,
• crosstalk,
• short-circuit,
• mismatched pairs,
• bad contacts,
• no shield etc..



• Testing of single and 3-phase ARC Welding equipment.
• Professional 3-phase portable appliance testing.
• Professional 3-phase machine testing
• Testing of Open-Circuit Voltage at ARC Welding Units in accordance to EN 60974-4.
• All tests on 3-phase electrical equipment can be carried out including live leakage test, power, polarity, RCD and Active polarity.
• Simple connection to the PAT/MACHINE tester with automatic detection



• Both IP (inductive) & IG (contact) RPM;
• ms Fuel-injection on time;
• % Duty cycle;
• Dwell angle;
• 1000V TRMS AC, DC voltage measurement;
• 10A TRMS AC, DC current measurement;
• 6uF..2mF Capacitance measurement;
• 600O..60MO Resistance measurement;
• Electric field detection;
• Temperature measurement(thermocouple type K included)



• TRMS AC voltage and current measurement.
• Frequency measurement.
• Power: measures various power parameters (active, reactive, apparent power, THD, PF, phase displacement).
• Intelligent loss analysis: complex algorithms detect loss and allow determining possible reasons for current loss.
• Harmonics: measures current or voltage harmonic components and a percentage value of a harmonic up to the 49th.
• Total Harmonic Distortion (THD)
• Power Factor (PF).



• PAT Demoboard is intended for demonstration of electrical equipment safety management.
• Presentation of safety management of electrical equipment in seminars, courses.
• Presentation of typical safety problems on electrical equipment.
• Practical demonstration of measuring instruments (performing tests, making right connections, analysing measured results).
• Continuity of equipotential bonding
• Insulation resistance
• Leakage current
• Touch leakage current
• Polarity of cables
• Functional operation



• Continuity tests (200 mA, 4 A, 10 A, 25 A).
• Insulation resistance.
• Substitute leakage current.
• Differential leakage current.
• Touch leakage current.
• IEC cord polarity test.
• Leakage and load TRMS current measurement with current clamp.



• TRMS AC, DC voltage measurement;
• TRMS AC current measurement;
• Resistance measurement;
• Frequency measurement;
• Continuity test (acoustic signaling);
• Power parameters measurement.



• large 2-line 500.000 counts LCD display
• 1000V TRMS AC, DC voltage measurement;
• 10A TRMS AC, DC current measurement;
• 50nF..25mF Capacitance measurement;
• 500O..50MO Resistance measurement;
• Diode test;
• 5Hz..1MHz Frequency of digital signals measurement
• Temperature measurement(thermocouple type K included)



• Supports all types of earthing resistance measurements:
• - Standard earthing resistance measurement with spikes
• - Selective earthing resistance test with one current clamp
• - Selective (contactless) earthing resistance with two current clamps
• - Specific earth resistance measurement
• Leakage current tests with current clamps
• Load current tests with current clamps
• High accuracy, very high immunity against external noise
• Preprogrammed limits



• Insulation resistance with DC voltage
• Continuity of PE conductors with 200 mA test current with polarity change
• Continuity of PE conductors with 7 mA test current (continuous measurement) without RCD tripping
• Line impedance
• Loop impedance
• Loop impedance with Trip Lock RCD function
• TRMS voltage and frequency
• Phase sequence
• RCD testing (general and selective, type AC, A and B)
• Earth resistance (3-wire method).
