Brand: Hameg

Generator de functii arbitrare 50 MHz Hameg HMF2550

Cod: Hameg HMF2550




Brosura produs PDF, 0.96 Mb

Descriere

  • Frequency Range 10µHz…50MHz
  • Output Voltage 5mVpp…10Vpp (into 50O) DC Offset ±5mV…5V
  • Arbitrary Waveform Generator: 250MSa/s, 14Bit, 256kPts
  • Sine, Square, Pulse, Triangle, Ramp, Arbitrary Waveforms incl. Standard Curves (white Noise, Cardiac etc.)
  • Total harmonic Distortion 0.04% (f <100kHz)
  • Burst, Sweep, Gating, external Trigger
  • Rise Time <8ns, in Pulse Mode 8…500ns Variable-Edge-Time
  • Pulse Mode: Frequency Range 100µHz…12.5MHz [25MHz], Pulse Width 15ns…999s, Resolution 5ns
  • Modulation Modes AM, FM, PM, PWM, FSK (int. and ext.)
  • 10MHz Timebase: ±1ppm TCXO, rear I/O BNC Connector
  • Front USB Connector: Save and Recall of Waveforms and Settings
  • 8.9cm (3.5") TFT: crisp Representation of the Waveform and all Parameters
  • USB/RS-232 Dual-Interface, optional Ethernet/USB or IEEE-488 (GPIB)


Accesorii standard

  • Line cord
  • Operating manual
  • CD


Optiuni recomandate

  • HO730 Dual-Interface Ethernet/USB
  • HO740 Interface IEEE-488 (GPIB), galvanically isolated
  • HZ13 Interface cable (USB) 1.8 m
  • HZ14 Interface cable (serial) 1:1
  • HZ20 Adapter plug BNC plug - 4 mm safety sockets
  • HZ24 Attenuators 3/6/10 and 20 dB
  • HZ33 Test cable BNC plug - BNC plug 0.5 m
  • HZ34 Test cable BNC plug - BNC plug 1.0 m
  • HZ42 19’’ Rackmount kit 2RU
  • HZ72 IEEE-488 (GPIB) Cable 2 m
