Order Number	Voltage (V)	Current (A)	Power(kW)
HEA-PS9080-50	0 � 80 V	0 � 50 A	1,5
HEA-PS9300-15	0 � 300 V	0 � 15 A	1,5
HEA-PS9080-100	0 � 80 V	0 � 100 A	3
HEA-PS9300-25	0 � 300 V	0 � 25 A	3
HEA-PS9600-15	0 � 600 V	0 � 15 A	3
HEA-PS9080-200	0 � 80 V	0 � 200 A	6
HEA-PS9160-100	0 � 160 V	0 � 100 A	6
HEA-PS9300-50	0 � 300 V	0 � 50 A	6
HEA-PS9600-25	0 � 600 V	0 � 25 A	6
HEA-PS9080-300	0 � 80 V	0 � 300 A	9
HEA-PS9240-100	0 � 300 V	0 � 100 A	9
HEA-PS9300-75	0 � 240 V	0 � 75 A	9
HEA-PS9750-25	0 � 750 V	0 � 25 A	9

Optiuni recomandate

HEA-PS9-xxx	HEA-PS9000 Options	Interfaces
HEA-PS9-QS	HEA-PS9000 Options	Source-Sink
HEA-PS9-W	HEA-PS9000 Options	water cooled

Alte produse HEIDEN

Brand: Heiden

SURSA DE PUTERE DC 3.3~15KW CU AUTOSCALARE HEIDEN HEA-PS-8000-3U

• Power: 1.5kW, 3kW, 6kW or 9kW
• DC Voltage: 0 up to 1500V
• DC Current: 0 up to 510A
• Wide-range input and active PFC
• Operating modes: CV, CC and CP from 1 kW
• OVP and OTP
• programmable, remote-controlled exchangeable interface boards as IEEE488, RS-232, USB, CAN, Profibus and LAN

Brand: Heiden

SURSA DE PUTERE AC CURENT ALTERNATIV MONO SI TRIFAZATA HEIDEN HE-ACS

• Power range from 250 VA to 10 kVA
• Output voltage from 0-700 V AC and 1000 V DC per phase
• Variable frequency from 1 to 2000 Hz,
• Wave forms sine, triangle and rectangle
• Maximum current up to 80 A per phase
• Simulation of 1 or 3 phases

Brand: Heiden

SURSA DE INALTA TENSIUNE PANA LA 70KV HEIDEN HE-XPSX

• AC mains supplied, modular HV PS in the range of 300 W to 800 W
• High voltages from 1 kV up to 70 kV
• Extraordinary control characteristics for output voltage and current.
• C-charger (KPS and LPS series) with very low output voltage overshoot
• State-of-the-art resonant converter topology, low EMI

Brand: Heiden

SURSA DE TENSIUNE DC PUTERE 3~10KW HEIDEN HE-LAB/SMS

• Power: 3kW, 4kW, 5kW, 6kW, 8kW or 10kW models
• DC Voltage: 0 up to 1200V
• DC Current: 0 up to 500A
• Efficiency up to 94 %
• Compact Design
• Active and Parallel connectable
• Digital Interfaces IEEE 488, RS232/485, USB and LAN (optional)
• Datalog function

Brand: Heiden

SURSA DE ALIMENTARE DC REGLABILA 0.6~3KW CU AUTOSCALARE HEIDEN HEA-PS-8000-2U

• Power: 0.6kW, 1kW, 1.5kW or 3kW
• DC Voltage: 0 up to 720V
• DC Current: 0 up to 120A
• Wide-range input and active PFC
• Operating modes: CV, CC and CP from 1 kW
• OVP and OTP
• programmable, remote-controlled
• exchangeable interface boards as IEEE488, RS-232, USB, CAN, Profibus and LAN on request

Brand: Heiden

SURSA DC MODULARA DE CURENTI INALTI HEIDEN 1140

• DC Voltage: 0 up to 30V
• DC Current: 0 up to 6000A
• Modular power
• at any time, can be enhanced
• Digital control
• extensive interfaces: analog, RS-484, RS-485, TCP / IP, Profibus
• novel encapsulated air cooling system
• individual voltages on request

Brand: Heiden

SURSA LINIARA DE TENSIUNE 750W~15KW TDK LAMBDA GENESYS

• Power: 750W, 1500W, 2.4kW, 3.3kW, 5kW, 10kW or 15kW models
• DC Voltage: 0 up to 600V
• DC Current: 0 up to 1000A
• Very compact design
• Wide input range
• Active PFC (typically 99%)
• Built-in RS232/RS485
• 16-Bit AD/DA converters

Brand: Heiden

SURSA DE TENSIUNE REGLABILA 0.3~1.5KW CU AUTOSCALARE HEIDEN HEA-PS-8000-DT

• Power: 0.3kW, 0.6kW, 1kW or 1.5kW
• DC Voltage: 0 up to 360V
• DC Current: 0 up to 60A
• Wide-range input and active PFC
• Operating modes: CV, CC and CP from 1 kW
• OVP and OTP
• programmable, remote-controlled
• various interfaces such as IEEE488, RS-232, USB, CAN and LAN on request

Brand: Heiden

SURSA DC DE CURENT INALT 120KW HEIDEN 1138/ 1139

• Power: up to 120kW
• DC Voltage: 0 up to 50V
• DC Current: 0 up to 24000A
• customized configuration
• robust and inexpensive
• Sense, soft start
• remote control, analog, freely definable voltages and currents up to max. 75 kW
• RS485, LAN, Profibus
• Water cooling

Brand: Heiden

SURSA DE TENSIUNE REGLABILA 0.3~1.5KW CU AUTOSCALARE HEIDEN HEA-PS-8000-T
