USB Modular Data Acquisition Unit USB 16-channels 100kSa/s Keitlhey KUSB-3102

Code: Keitlhey KUSB-3102




Datasheet PDF, 1.85 Mb

Description

  • USB 2.0 and USB 1.1, true plug-and-play compatibility
  • 16 SE/pseudo-DI/ 8 DI analog input channels
  • 12-bit resolution
  • High and low programmable gains
  • Input/output speeds up to 100kS/s
  • Up to 17 digital I/O lines
  • 500V isolation barrier protects the computer and module from voltage spikes, ESD, and surges
  • Runs under Windows® 2000 and XP platforms
