Multimetru digital de precizie 5.5 digit TTi 1906

• 1 µHz to 25 MHz range(sine and square)
• 1 µHz resolution
• 128K points at up to 125MS/s Arbitrary waveforms
• True pulse generator with variable delay and variable rise/fall



• Extends the output range of function generators
• 30 Volts peak to peak output swing
• DC to 1MHz bandwidth
• High impedance input, 0dB to +20dB gain
• 50 Ohm and 600 Ohm outputs
• 20dB swtitchable output attenuator



• 0.03Hz to 3MHz frequency range
• External seven digit 120MHz counter
• Simultaneous display of frequency & amplitude
• High waveform quality at all frequencies & levels
• 2mV to 20V pk-pk from 50 Ohms or 600 Ohms



• 40MHz D.D.S. function generator with arbitrary capability
• 0.1mHz to 40MHz (50MHz square) rang
• 10 digit resolution



• 0.001Hz to 10MHz frequency range
• 6 digits or 1mHz resolution
• 1ppm stability and 10ppm one year accuracy
• Low distortion, high spectral purity sine waves



• 0.03Hz to 3MHz frequency range
• Simultaneous display of frequency & amplitude
• High waveform quality at all frequencies & levels
• 2mV to 20V pk-pk from 50 Ohms or 600 Ohms



• 40 MHz sine
• 50 MHz square
• Dual channel independent or linked
• 100 MSa/s sample rate
• 12-bit vertical resolution



• 1MHz to 1300MHz frequency range
• Resolution bandwidths of 1MHz, 280kHz or 15kHz
• -96dBm typical noise floor at -20dBm reference level
• Measurement in dBm or dBµV, mV or µW
• Zero span mode with AM and FM audio demodulation



• 16 MHz sine and square
• Single channel
• 40 MSa/s sample rate
• 12-bit vertical resolution



• High power 35V/10A & 18V/20A
• Compact & lightweight high power units
• Bench or rack mounting, front & rear terminals
• Very low noise, excellent transient response
