Multimetru de laborator 4½ digit TTi 1705

• 0.03Hz to 3MHz frequency range
• External seven digit 120MHz counter
• Precision internal lin/log sweep
• Internal/external AM up to 100%
• Simultaneous display of frequency & amplitude
• High waveform quality at all frequencies & levels
• 2mV to 20V pk-pk from 50 Ohms or 600 Ohms



• Wide voltage and current range, 0 to 80 V and 0 to 80 A
• 300 watts continuous dissipation at 40 degrees C
• Versatile solution for testing dc power sources



• 1MHz to 2700MHz frequency range
• Resolution bandwidths of 1MHz, 280kHz or 15kHz
• -96dBm typical noise floor at -20dBm reference level
• Measurement in dBm or dBµV, mV or µW
• Zero span mode with AM and FM audio demodulation



• Frequency, period, pulse width, frequency ratio, duty cycle, and event counter modes
• DC to 6000MHz range, 0.001mHz resolution
• High impedance measurement up to 125 MHz
• AC or DC coupling, 1M/50Ohm selection, polarity invert
• Switchable attenuator, threshold control



• 4.5 digit dual LCD
• Dual 12,000 count, auto/manual ranging
• Accuracy and resolution: 0.04%, 10uV, 10mW
• Dual displays & dual measurement technology
• True RMS ac functions, Frequ., Capacitance



• Single outputs, 35V/5A, 18V/10A, 42V/10A, 20V/20A
• Dual or triple outputs, 35V/4A
• Independent digital voltage and current meters for each output
• 4 digit resolution



• 40 MHz sine
• 50 MHz square
• 4-channel independent or linked
• 100 MSa/s sample rate
• 12-bit vertical resolution



• 10MHz to 3600MHz or 6000MHz frequency range
• Resolution bandwidths from 300Hz to 10MHz (1:3:10)
• -120dBm typical noise floor at -40dBm ref. level/10kHz RBW
• Measurement in dBm or dBuV, mV or uW
• Zero span mode with AM and FM audio demodulation
• Trace modes of normal, peak hold and trace average
• USB interfaces for Flash drives and PC connection



• 1 µHz to 25 MHz range(sine and square)
• 1 µHz resolution
• 128K points at up to 125MS/s Arbitrary waveforms
• True pulse generator with variable delay and variable rise/fall



• 40,000 counts, auto/manual ranging
• Accuracy and resolution, 0.08%, 10µV, 10mW
• Large and bright LED display (14mm/0.56")
• True RMS ac functions, wide ac bandwidth
• Frequency measurement
