Generator semnal RF 10 MHz..6 GHz TTi TGR6000

• 10 MHz ..26.5 GHz bandwidth
• Measurement range from -50 dBm to +20 dBm
• Replacement solution for conventional power meter and sensor combination
• Simple USB connection to laptop or PC
• Use multiple sensors on one laptop or PC



• 3 Hz to 3 GHz in two overlapping ranges
• Large 8.5 digit display with full range of annunciators
• Battery operation and lightweight, handheld format



• 16 MHz sine and square
• Dual channel independent or linked
• 40 MSa/s sample rate
• 12-bit vertical resolution



• Frequency, period, pulse width, frequency ratio, duty cycle, and event counter modes
• DC to 6000MHz range, 0.001mHz resolution
• High impedance measurement up to 125 MHz
• AC or DC coupling, 1M/50Ohm selection, polarity invert
• Switchable attenuator, threshold control



• Wide voltage and current range, 0 to 80 V and 0 to 80 A
• 300 watts continuous dissipation at 40 degrees C
• Versatile solution for testing dc power sources



• 40 MHz sine
• 50 MHz square
• 4-channel independent or linked
• 100 MSa/s sample rate
• 12-bit vertical resolution



• 0.03Hz to 3MHz frequency range
• External seven digit 120MHz counter
• Precision internal lin/log sweep
• Internal/external AM up to 100%
• Simultaneous display of frequency & amplitude
• High waveform quality at all frequencies & levels
• 2mV to 20V pk-pk from 50 Ohms or 600 Ohms



• 10MHz to 6000MHz frequency range
• 10Hz setability, +/-1ppm frequency stability
• Locking to external frequency standard
• -110dBm to +7dBm amplitude, 0.1dB steps
• Full remote control through RS232, USB, LAN and GPIB



• 5½ digits (±210,000 counts), auto/manual range
• 1µV, 1nA, 1mOhm resolution, 0.012% accuracy
• Wide range of computing functions included
• Automatic data logging functions included
• Integral True RMS AC converter



• Extends the output range of function generators
• 30 Volts peak to peak output swing
• DC to 1MHz bandwidth
• High impedance input, 0dB to +20dB gain
• 50 Ohm and 600 Ohm outputs
• 20dB swtitchable output attenuator
