Sursa cuadrupla programabila de precizie Hameg HMP4040

• 70 MHz bandwidth
• 2 analog channels and MSO (Mixed Signal Opt. HO3508) with 8 Logic Channels
• 2 GSa/s sample rate on 1 channel, 1 GSa/s on 2 channels



• 100 MHz bandwidth
• 4 analog channels and MSO (Mixed Signal Opt. HO3508) with 8 Logic Channels
• 2 GSa/s sample rate on 2 channels, 1 GSa/s on 4 channels



• Frequency Range 10µHz…25MHz
• Output Voltage 5mVpp…10Vpp (into 50O) DC Offset ±5mV…5V
• Arbitrary Waveform Generator: 250MSa/s, 14Bit, 256kPts
• Sine, Square, Pulse, Triangle, Ramp, Arbitrary Waveforms incl. Standard Curves (white Noise, Cardiac etc.)



• Frequency Range 100kHz…1.6GHz
• Tracking Generator HMS1010 -20…0dBm
• Amplitude Measurement Range -114…+20dBm
• DANL -135dBm with Preamp. Option HO3011
• Sweep Time 20ms…1,000s
• Resolution Bandwidth 100Hz…1MHz in 1-3 Steps, 200kHz (-3dB); additional 200Hz, 9kHz, 120kHz, 1MHz (-6dB)



• 40 MHz bandwidth
• 2 analog channels
• Time Base 100ns/div."¦0.2s/div., with X magnification to 10ns/div



• 4 x 0…32V/0…10A 384W max.
• 384W Output Power realized by intelligent Power Management
• Low Residual Ripple: <150µVrms due to linear Post Regulators
• High Setting- and Read-Back Resolution of 1mV up to 0.2mA



• 2 x 0…20V/0.5A 1 x 5V/1A
• 3-Digit switchable Displays (Display Resolution 0.1V/1mA)
• Pushbutton for Activating/Deactivating all Outputs
• Adjustable Current Limiting and Electronic Fuse



• 100 MHz bandwidth
• 2 analog channels and MSO (Mixed Signal Opt. HO3508) with 8 Logic Channels
• 2 GSa/s sample rate on 1 channel, 1 GSa/s on 2 channels



• 200 MHz bandwidth
• 2 analog channels and MSO (Mixed Signal Opt. HO3508) with 8 Logic Channels
• 2 GSa/s sample rate on 1 channel, 1 GSa/s on 2 channels



• 3 x 0…32V/0…10A 384W max.
• 384W Output Power realized by intelligent Power Management
• Low Residual Ripple: <150µVrms due to linear Post Regulators
• High Setting- and Read-Back Resolution of 1mV up to 0.2mA
