Multimetru digital programabil 4.75 digit Hameg HM8012

• 70 MHz bandwidth
• 4 analog channels and MSO (Mixed Signal Opt. HO3508) with 8 Logic Channels
• 2 GSa/s sample rate on 2 channels, 1 GSa/s on 4 channels



• 100 MHz bandwidth
• 2 analog channels and MSO (Mixed Signal Opt. HO3508) with 8 Logic Channels
• 2 GSa/s sample rate on 1 channel, 1 GSa/s on 2 channels



• 350 MHz bandwidth
• 2 analog channels and MSO(Mixed Signal Opt.HO3508 [HO3516]) with 8 [16] Logic Channels
• 2 GSa/s sample rate on each channel, 4 GSa/s on half-channel



• 2 x 0…20V/0.5A 1 x 5V/1A
• 3-Digit switchable Displays (Display Resolution 0.1V/1mA)
• Pushbutton for Activating/Deactivating all Outputs
• Adjustable Current Limiting and Electronic Fuse



• Frequency Range 10µHz…50MHz
• Output Voltage 5mVpp…10Vpp (into 50O) DC Offset ±5mV…5V
• Arbitrary Waveform Generator: 250MSa/s, 14Bit, 256kPts
• Sine, Square, Pulse, Triangle, Ramp, Arbitrary Waveforms incl. Standard Curves (white Noise, Cardiac etc.)



• 3 x 0…32V/0…10A 384W max.
• 384W Output Power realized by intelligent Power Management
• Low Residual Ripple: <150µVrms due to linear Post Regulators
• High Setting- and Read-Back Resolution of 1mV up to 0.2mA



• Outstanding Frequency Range 1Hz…1.2GHz
• Output Power -127…+13dBm
• Frequency Resolution 1Hz (Accuracy 0.5ppm)



• Frequency Range 10µHz…25MHz
• Output Voltage 5mVpp…10Vpp (into 50O) DC Offset ±5mV…5V
• Arbitrary Waveform Generator: 250MSa/s, 14Bit, 256kPts
• Sine, Square, Pulse, Triangle, Ramp, Arbitrary Waveforms incl. Standard Curves (white Noise, Cardiac etc.)



• Wide Measurement Range 1mW…8kW
• Voltage Range 100mV…500V, Current Range 1mA…16A
• Frequency Range DC…1kHz
• Simultaneous Voltage, Current and Power Display
• Display of apparent, effective and reactive Power
• Power Factor Display



• 150 MHz bandwidth
• 2 analog channels and MSO (Mixed Signal Opt. HO3508) with 8 Logic Channels
• 2 GSa/s sample rate on 1 channel, 1 GSa/s on 2 channels
