Frequency Range: 20 MHz to 300 MHz
VSWR: 2.5:1 average
Polarization: Linear
Power Handling: 100 W maximum
Feedpoint Impedance: 50 ohms nominal
Improved balun provides superior patterns and balance
Improved biconical element design (patent pending)
Effective internal choke provides immunity to externally induced imbalance
Moderate power handling capability accommodates a wide range of immunity testing applications
Immunity and Emissions testing

More products TDK

Brand: TDK

WIDE BAND LOG PERIODIC DIPOLE ANTENNA 80 MHZ..3 GHZ TDK LPDA-0803

• Frequency Range: 80 MHz to 3 GHz
• Gain: 6 - 8 dBi
• VSWR: < 2:1 average
• Polarization: Linear
• Power Handling: 500W CW
• Feedpoint Impedance: 50 ohm nominal

Brand: TDK

TRI-PLATE AND TABLE WITH E-FIELD GENERATING FOR EMC AUTOMOTIVE TESTING TDK TP-02

• Immunity measurements to automotive test regulations
• Excellent linear response
• Designed to SAE specifications
• Capable of handling high power
• Integrated test table

Brand: TDK

EMC PRECISION BROAD BAND HYBRID LOG PERIODIC ANTENNA 26 MHZ..1 GHZ TDK HLP-2601

• Frequency Range: 26 MHz to 1 GHz
• Gain: 6 to 8 dBi typical
• VSWR: 2:1 average
• Polarization: Linear
• Power Handling 3500W CW continuous

Brand: TDK

FULLY COMPLIANT 3M CISPR ANECHOIC CHAMBER 3M CISPR 26 MHZ..18 GHZ TDK

• Dimensions: 9.0 m long x 6.0 m wide x 5.4 m high (29'-6" L x 19'-8" W x 17'-8" H)
• Absorbers: IB-015 fully lined double layer ferrite tile IP-045C partially lined absorber
• EMI frequency range: 30 MHz - 18 GHz
• EMS frequency range: 26 MHz - 18 GHz
• Radiated emissions: Full compliance with ANSI C63.4, EN 50147-2, CISPR 22
• Radiated immunity: Full compliance with IEC 1000-4-3

Brand: TDK

COMPACT HYBRID LOG PERIODIC ANTENNA 30 MZ..3 GHZ TDK HLP-3003C

• Frequency Range: 30 MHz to 3 GHz
• Gain: 6 dBi typical
• VSWR: 2:1 average
• Polarization: Linear
• Power Handling: 100 W
• Shortest antenna length available for the operating frequency range

Brand: TDK

INTEGRATED RADIATED/ CONDUCTED EMS TEST SYSTEM TDK EMS-TS

• Best-in-Class Test Instruments
• Fully Integrated Hardware and Software
• Remote Control of Switches and Positioning Devices
• Automated, Semi-automated, and Manual Testing
• Built-in System and Operator Safety
• Ergonomically Designed Test Consoles and Racks
• High Quality System Cabling and Connectors
• Quality Workmanship
• On-Site Training
• Comprehensive Warranty

Brand: TDK

COMPACT FULLY COMPLIANT ANECHOIC CHAMBER 26 MHZ..1 GHZ TDK CAC-S™ 2601

• Dimensions: 7.0 m long x 3.0 m wide x 3.0 m high
• Absorbers: X-131 Fully lined double layer ferrite
• Radiated emissions: Compliance with EN 50147-2
• Radiated immunity: Compliance with IEC 1000-4-3
• EMI frequency range: 30 MHz - 1 GHz
• EMS frequency range: 26 MHz - 1 GHz
• Radiated emissions: Pre-compliance with EN 50147-2, ANSI C63.4, CISPR 22
• Radiated immunity: Full compliance with IEC 1000-4-3

Brand: TDK

WIDE BAND LOG PERIODIC DIPOLE ANTENNA 800 MHZ..3 GHZ TDK LPDA-8003

• Fquency Range: 800 MHz to 3 GHz
• Gain: 8 dBi
• VSWR: 2:1 average
• Polarization: Linear
• Power Handling: 500W CW
• Feedpoint Impedance: 50 ohms nominal
• Compact broadband design

Brand: TDK

V-LOG PERIODIC ARRAY ANTENNA 200 MHZ..1 GHZ TDK VLA-2001

• Frequency Range: 200 MHz to 1 GHz
• Gain: 8 dBi
• VSWR: 1.5:1 average
• Polarization: Linear
• Power Handling: 2.5 kw
• Impedance: 50 ohms nominal
• High power up to 2500 W

Brand: TDK

HIGH POWER EMC BROADBAND ANTENNA 25..100 MHZ TDK HPBA-2510

• Frequency Range: 25 MHz to 100 MHz
• VSWR: 5.8:1 max, 2.5:1 typical
• Polarization: Linear
• Power Handling: 3500 W maximum (10,000 W model available)
• Improved impedance matching
