Dinamometru masurare forta inalta 20kg EXTECH 475044

Cod: EXTECH 475044




Brosura produs PDF, 0.36 Mb

Descriere

Extech 475044: High Capacity Force Gauge



Push/Pull measurements in kg, lbs, oz and Newton units with ±0.5% accuracy



475044 is a High Capacity Force Gauge with a 5 digit LCD display and peak hold. Exclusive load cell measurement transducer. Over-range, low battery and advanced function indicators. 20kg/44.1 lbs/196.1 Newtons measurement capacity. Selectable fast/slow response times. Basic accuracy of 0.5%. Display reverses to match viewing angle. Complete with tension rod, carrying case and 4 adapters (flathead, cone, chisel and hook for tension), and 6 AA batteries.



  • Range: 44 lbs, 20kg, 196 Newtons (±0.5% accuracy)
  • Ideal for a wide variety of applications in the electronics, automotive, chemical, plastics and machinery industries
  • Reversible display and fast/slow response mode
  • Exclusive load cell measurement transducer
  • Overrange, low battery and advanced function indication
  • Zero Adjust push-button and Peak Hold switch
  • Complete with hook adaptor for tension/compression adaptors, 5" extension rod, 6 AA batteries and carrying case



Specifications

Range

Range

44lbs, 20kg, 196 Newtons

Basic Accuracy (23°C)

±(0.5%)

Resolution

0.01lbs, 0.01kg, 0.05 Newtons

Overload capacity

30kg

Update Rate

Fast mode 0.2secs; Slow mode 0.6secs

Full scale deflection

2.00mm

Transducer type

Load cell

Dimensions/ Weight

8.5x3.5x1.8" (215x90x45mm)/ 1.4 lbs (650g)
