BAUR TG 20/50 Audio frequency transmitter

• 3 voltage shapes in one device: VLF truesinus®, VLF square wave and DC voltage
• For medium-voltage cables of up to 50 kV operating voltage
• Cable testing, fault conditioning, cable sheath testing



• Fast and reliable
• Precise, dependable cable fault location
• High performance high voltage unit
• Integrated proven cable fault pre-location methods



• Testing as DC or Dc testing device
• Polarity of the DC voltage can easily be reversed
• Robust and durable



• Clear phase determination possible in cable lengths up to 40 km
• Highest level of safety when used on earthed and shorted cables in compliance with EN 50110-1 (DIN VDE 0105-100)
• Suitable for all switchgear constructions due to compact design of the signal injectors
• Ready for operation for up to 2 weeks (standby mode)



• High surge voltage up to 32 kV
• Continuously adjustable voltage
• Voltage monitoring through kV meters with 3 measuring ranges
• Automatic discharge unit



• Initial rapid condition evaluation of switchgear and cable accessories during mains operation
• Ideal for quick checks of MV and HV switchgear



• Output energy up to 50 VA
• Automatic or manual impedance adjustment
• Charging unit and rechargeable battery integrated; battery or mains operation
• Continuous or cyclical output



• Automatic PD detection during normal mains operation (without switching off the cable route)
• With DeCIFer® technology: PD identification based on 500 million measurement results
• Precise online PD mapping with PD transponder



• Fast and exact location of position and laying depth of cables
• Intuitive operation ½ no special measurement knowledge required
• Lightweight and manageable



• Configurable for various measurement ranges and cable types
• Standard-compliant, safe measurements on live cables through the measurement category CAT IV / 600 V
• Ideal for fault location in the area of telecommunication, video technology, data and security technology
