BAUR TDR 500/510 Time domain reflectometer

• Fast and reliable
• Precise, dependable cable fault location
• High performance high voltage unit
• Integrated proven cable fault pre-location methods



• 3 voltage shapes in one device: VLF truesinus®, VLF square wave and DC voltage
• For medium-voltage cables of up to 50 kV operating voltage
• Cable testing, fault conditioning, cable sheath testing



• Cable and cable sheath testing up to 10 kVC
• Resistance measurement
• Cable and cable sheath fault pre-location with precision measuring bridge
• Adjustable cable sections that can be defined with length, conductor cross-section and material respectively and can be considered in the distance calculation



• Configurable for various measurement ranges and cable types
• Standard-compliant, safe measurements on live cables through the measurement category CAT IV / 600 V
• Ideal for fault location in the area of telecommunication, video technology, data and security technology



• Cable identification on all types of de-energised cables
• Reliable verification of the cable identification by means
• of the highly precise three-factor-analysis ATP
• Safe cable identification on live low-voltage cables
• Connection technology according to CAT IV/600 V



• Fully automatic measurement sequence
• Suitable for mineral or silicone oils and easther liquids
• Reliable, reproducible measurement results using the latest measument technology
• Designed for daily countinous operations in laboratories



• Testing of medium- and high-voltage cables
• DC voltage testing of up to 70 kV output voltage with positive or negative polarity
• AC voltage testing - up to 55 kV for switchgear, busbars and insulating elements
• Easy-to-maintain 2-piece design



• Inline insulating oil testing in oil preparation systems
• Quality assurance during production processes
• Improved, easy oil sample handling
• Integration in existing production process control possible



• Clear phase determination possible in cable lengths up to 40 km
• Highest level of safety when used on earthed and shorted cables in compliance with EN 50110-1 (DIN VDE 0105-100)
• Suitable for all switchgear constructions due to compact design of the signal injectors
• Ready for operation for up to 2 weeks (standby mode)



• Compact and robust device for portable use onsite
• Test voltages from 0 to 75 kVrms
• Repeatable breakdown measurements in mineral, silicone and plant oils
• Reliable measurement results due to its short switch-off time (< 10 ½s)
