PITE 3551S Single Phase Meter Tester is widely used in power utility, substation, telecom machine room and the alike for power consumption examination, circuit breakage inspection, power abnormality analyzing, asset management and industrial production management.

It is functional in field-testing for all single phase energy meters. It is widely used in power utility, substation, telecom machine room and the alike for power consumption examination, circuit breakage inspection, power abnormality analyzing, asset management and industrial production management. It is light-weight with touch screen and keypad operation, smart, easy going and what is more cost effective.

Technical specifications

Voltage signal input: Direct input
Resistance:	>2MO, 20pF
Testing range:	10~500Vrms
Peak voltage:	700V
Power consumption:	<0.5VA/phase
Current input circuit
Indirect input, with different optional CT
Testing range:	20Arms, 60Arms, 100Arms
Power consumption:	<2.0VA/phase
Frequency range:	40 Hz ~70Hz
Screen:	320*240, 3.5’ TFT LCD touch-screen
Internal Memory:	16 MB Flash
External Memory:	256MB
Com port:	USB port
Data records:	1000
Power supply:	rechargeable Li-ion battery workable for 5~6 hours
Power adaptor:	AC100~240V/DC16.8V-1A
Main unit:	0.7kg, 277�169�36mm mm
Working temperature:	-20�C ~ 40�C
Relative humility:	5~90%RH
Insulation:	>100MO, AC2kV/50Hz, 1 min

Functions

Item	Function	Description
1	Measurement	Single phase metering unit Single phase energy meter
2	CT Ratio (optional)	Measure CT ratio and angle difference
3	Online recording	Active energy, reactive energy and power factor

Other specifications

Item	Range	Accuracy
Voltage	10~500Vrms	±0.5%
Current	Optional for 20A, 60A, 100A and 500A	±0.5%
Frequency	40~70Hz	±0.01Hz
Phase	0~360°	±0.5°
Active power		±0.5%
Reactive power		±1.0%
Active energy		±0.5%
Reactive energy		±1.0%
Power factor	-1.00~1.00	±0.005
Impulse constant	FL = 3600�(5/Ie)P/kW�h Ie: CT range
