PC Based Power Electronics Trainer ED-1430

Cod: ED-1430




Brosura produs PDF, 1.23 Mb

Descriere

CONFIGURATION

  • ED-1430 : PC Based Power Electronics Trainer
    • Number of modules : 5ea
    • Module dimension : 290(W) x 210(H) x 26(D)mm
    • Module storage cabinet(1ea) : 596(W) x 318(H) x 255(D)mm
  • Required System
    • DS-1410 : Docking Station(Option)
      • Please refer to page 24 on DS-1410 specifications
    • CBIS-1400 : Computer Based Instrument System(Option)
      • Please refer to page 22 on CBIS-1400 specifications
    • Computer(Option)



SPECIFICATIONS

  • Pentium IV or above 1.7GHz or above
  • RAM 512M or higher
  • Hard Disk Min. 500Mbyte free space
  • USB 2.0 compatible
  • Windows NT4.0/2000/XP (Recommended OS : Windows XP)



ACCESSORIES

  • Connection cord : 1set
  • AC Power Cord : 1ea
  • Program CD : 1set
  • User’s manual : 1ea
