Transmodulator DVB-T -> DVB-T Promax DT-212

Cod: Promax DT-212




Brosura produs PDF, 0.2 Mb

Descriere

The DT-212 is a DVB-T to DVB-T (COFDM) transmodulator. It has a direct COFDM input that can be tuned to any multiplex and ouput in the UHF band. They are agile in frequency and output level.

This module allows to regenerate the quality of the multiplex when received from a noisy source. It is also interesting to change the input channel to another channel with total quality preservation.





RF INPUTS
  Connector

2 independent DVB-T inputs
BNC-Type female, Impedance 75 ?

RF OUTPUT
  Connector

2 combined independent DVB-T multiplexes
F-Type female, Impedance 50 ?

TS PROCESSING
  Filtering
  Measurements


PID Filtering with Filtering Table up to 32 PID
Bitrate of the Output Multiplex
Percentage of used bitrate relative to the maximum capacity of the multiplex

CONFIGURATION AND
POWER SUPPLY


Through the DT-800 control and power supply unit. Control can be made remotely from a PC



Optiuni recomandate

DT-800B

Control unit and power supply.

DT-802

Control unit and redundant power supply modules.

DT-900

Rack and wall mounted structure.

DT-900B

Rack mounted structure.

DT-901

Empty module plates..

DT-902B

Power CAM modules for smart cards..

CC-043

Supply and control cable with 3 connexions for DT-800B (included)

CC-044

Supply and control cable with 4 connexions for DT-800B (included)

CC-143

Supply and control cable with 3 connexions for DT-802 (included)

CC-144

Supply and control cable with 4 connexions for DT-802 (included)

OP-XXX-V

Output in the range 170-650 MHz for modules with DVB-T..

OP-800-P

Option required to use DT-800B with 3 x DT-730 modules

OP-212-D

Dual independent output for DT-212B

OP-504-S

TS-ASI output option for DT-504B







RECEIVERS WITH ASI-TS OUTPUT

DT-302

Dual DVB-S/S2 receiver with CAM, ASI-TS output.

DT-312

Dual DVB-T receiver, ASI-TS output.

DT-324-M

IP receiver to ASI-TS output (MPTS).

DT-324-S

IP receiver to ASI-TS output (SPTS).







IP STREAMERS

DT-421-M

IP Streamer. ASI-TS inputs, IP output (MPTS)

DT-421-S

IP Streamer. ASI-TS inputs, IP output (SPTS)







COMBINERS - AMPLIFIERS

DT-700

4x1 quadruple DVB-T combiner .

DT-710

8 input DVB-T combiner with a 117 dBuV (+10 dBm) one

 single output.

DT-722

4 input DVB-T combiner with a 129 dBuV / 250 mW (+22 dBm)

 one single output.

DT-730

DVB-T amplifier with a 137 dBuV / 1 W (+30 dBm).

DT-610

Optical transmitter module

DT-620

Optical receiver module
