Fluid Process Control Trainer ED-FPC

Cod: ED-FPC




Brosura produs PDF, 0.86 Mb


Descriere

EXPERIMENTS

  • Sensor output characteristics by the change of physical volume
  • Basic control programming essential for instrumentation control
  • Level control using the Analog Ultrasonic Sensor
  • Measurement of a storage tank’s pressure using the Analog Pressure Sensor
  • Measurement of the fluid’s flow inside a pipe using the Analog Flow Sensor
  • Measurement of the water tank’s temperature using the Analog Temperature Sensor
  • Various control techniques using the PID Temperature Regulator



Features:

  • Control of pressure, flow, level and temperature which are essential for process control
  • Capable of stand-alone control and mixed combination in various types
  • Real-time measurement and monitoring using data collection and signal conditioning
  • Measurement of flow’s status and gain of the controlled data
  • Built-in temperature compensation system and correction system(Feedback System)
  • Analog element control using the pump’s speed control proportional control valve
  • Built-in PID control system
  • Standard Controller: PC based control(WAGO)
