Model	Choose SD3.0 Solution	Choose SD4.0 Solution	Choose NAND Flash Solution	Choose eMMC Solution
Standard Probe	SD3.0 Probe	SD4.0 Probe uSD4.0 Probe	NAND Flash Probe (including the Serial Flash, SPI NAND, SPI)	eMMC Probe
Optional Probe	SD4.0 Probe uSD4.0 Probe	-	-	-

Protocol Analyzer

• Real-time display of the eMMC 5.1, NAND Flash, SD3.0 or SD 4.0 (UHS-II) data

• eMMC 5.1, NAND Flash, SD3.0 or SD 4.0 (UHS-II) triggers

• Each protocol has its own probe for easier connection, better impedance, higher capture quality

• Filter specific data to save memory

• Hide specific data for easier reading

• Search specific data for easier finding

• Statistics for easier commands and data analysis

• Trigger commands or data for easier pinpoint

• Display data and waveforms together for better observation (excluding UHS-II)

• Two sets of voltage detects to detects voltage changes

• Use PC hard disk for long time protocol surveillance

Logic Analyzer

• 2.4GHz timing analysis

• 8-state flow chart eMMC5.1 / NAND Flash / SD3.0 / Serial Flash / SPI NAND / SPI triggers

• With waveforms eMMC5.1 / NAND Flash / SD3.0 / Serial Flash / SPI NAND / SPI decodes

• Stack with a DSO to form as an MSO
