Analizor de spectru modular rack 19inch 1Hz..30MHz Aaronia Spectran NF RSA5000

Cod: Aaronia Spectran NF RSA5000




Brosura produs PDF, 1.35 Mb

Descriere

  • Frequency range: 1Hz to 1MHz (30MHz)
  • Analog Input: 2µV to 200mV (typ.)
  • With opt. DDC:200nV to 200mV (typ.)
  • Resolution (RBW): 0,3Hz to 1MHz(1-3-10 step)
  • Units: Volt
  • Detectors: RMS, Min/Max
  • Demodulator: AM, FM
  • Input: N input (f)
  • Accuracy: 3% (typ.)
  • Interface: USB 2.0/1.1/LAN
  • Dimensions (L/W/D): 19 inch rack mount
  • Weight: 3450gr
  • Warranty: 2 years



Integrated PC:

  • CPU: Intel Celeron G530 2,4GHz
  • RAM: 2x2GB SO-DiMM DDR3, 1066MHz
  • HDD: 320GB (5400rpm)
  • External Ports: 2x USB 2.0, 2x USB 3.0, 1x Audio, 1x 10/100/1000 Mb/s Ethernet, 1x DVI-I (Analog,Digital), 1x HDMI, 1x eSATA
  • Power supply: 19,5V (7,9A max.)
  • Operatingsystem: Linux



Highlights:

  • Internet flash software updates
  • High-performance DSP (Digital Signal Processor)
  • Real-time remote control via USB
  • Audio out for the use of PC based FFT analyzer software
  • Very thick (3mm) aluminum housing offering very good screening
  • Free Mac OS, Linux and Windows software







Examples for possible analysis and measurements within frequency range (1Hz - 30MHz):

  • Traction power
  • Power lines and cables
  • Transformer
  • Power supplies and harmonics
  • Energy saving light bulbs
  • Switching power supplies
  • TFT and LCD monitors and TVs
  • 135kHz RFID
  • DSL
  • ADSL
  • VDSL
  • 13,56MHz RFID
  • Various home appliances, industry and office up to 30MHz


Accesorii standard

  • Low frequency SPECTRAN NF RSA 5000
  • Power supply
  • Cleaning brush
  • Detailed English manual (on CD)
  • USB controlled Analyzer software for Mac OS, Linux and Windows (on CD)
