WOHLER VIS400 Modular Video Inspection Camera System Professional

Standard accessories

Wöhler VIS 400 Cable Camera & Wöhler VIS 400 Cable Reel Camera

Scope of delivery

Wöhler VIS 400 color TFT monitor 7" with 4 GB SD card and power supply

Protection bag with glare protector and shoulder belt

Pan & tilt camera head Ø 40 mm

Light ring for Ø 40 mm head

Camera cable

Power supply

Plastic case



Wöhler VIS 400 Push Rod Camera

Scope of delivery

Wöhler VIS 400 color TFT monitor 7" with 4 GB SD card and power supply

Protection bag with glare protector and shoulder belt

Pan & tilt camera head Ø 40 mm

Light ring for Ø 40 mm head

10 replacement plastic domes

Roller guide

Camera head protection cage with cut-out

Viper with push rod

Plastic case

XXL Alu case

Recommended options

Wöhler VIS 400 Color Monitor

EN

Wöhler VIS 400 color monitor,protective bag with glare shield and shoulder belt, Mini-USBcable,

4 GB SD-Card, power supply and plastic case

4781 J

Monitor Article no.

Protection Sleeve

for Wöhler camera head Ø 40 mm

with cut-out

2641 J

Guidance Sleeve

for Wöhler mini camera head Ø 26 mm

3827 J

Guidance Sleeve with protection cage

for Wöhler mini camera head Ø 26 mm

3847 J

Protection Sleeves Article no.

Wöhler VIS Camera Heads Article no.

Wöhler Camera Head Ø 26 mm

detachable

flexible connection to the camera rod, with leather protection case

8920 J

Wöhler Camera Head Ø 40 mm

detachable, pan and tilt

flexible connection to camera rod, with leather protection bag

8930 J

Wöhler Camera Head Ø 51 mm b/w

detachable, pan & tilt

flexible connection to camera rod, with leather protection case

7801 J

Wöhler Camera Head Ø 51mm

detachable, pan & tilt

flexible connection to camera rod, with leather protection case

7806 J

Domes for Wöhler VIS Camera Heads Article no.

Replacement Plastic Domes (10 pcs.)

for Wöhler camera head Ø 40 mm

3675 J

Glass Dome

for Wöhler camera head Ø 40 mm

3674 J

Glass Dome

for Wöhler camera head Ø 51 mm

7802 K

Glass Dome with protection cage

for Wöhler camera head Ø 51 mm

3494 K

Plastic domes (5 pieces)

for Wöhler camera head Ø 51 mm

7075 K

Telescope Article no.

Wöhler Telescopic Tube 1.6m

with flexible gooseneck

for all camera heads, length of the telescopic tube 0.9-1.6 m plus gooseneck 0.3 m

7005 O

Wöhler Telescopic Tube 3.4m

with flexible gooseneck

for all camera heads, length of the telescopic tube 0.9-3.4 m plus gooseneck 0.3 m

7024 J

INTERNATIONAL@WOEHLER.DE WWW.WOEHLER-INTERNATIONAL.COM 19

VISUAL INSPECTION OF CHIMNEYS, PIPES, DUCTWORK, FLUES

Wöhler VIS 400 | Accessories

Camera Vipers Article no.

with push rod 20 m, Ø 6 mm 7308 J

with push rod 30 m, Ø 6 mm 7336 J

Wöhler Camera Viper

with digital meter counter, belt holder and stand

Wöhler Camera Viper

with digital meter counter, belt holder and stand

with push rod 20 m, Ø 6.5 mm 7302 J

with push rod 30 m, Ø 6.5 mm 7301 J

Wöhler Camera Viper

with digital meter counter, belt holder and stand

with push rod 20 m, Ø 7 mm 7309 J

with push rod 30 m, Ø 7 mm 7307 J

Accessories Article no.

Lowering aid

for camera cable & ropes

extendable from 22 - 40 cm

5706 I

Power Supply

for Wöhler VIS 2xx / VIS 3xx / VIS 400 cameras with 7" displays

approx. charge time 3 hours, with adaptors for all countries

3789 K

Car charger 18 V for

for Wöhler VIS 2xx / VIS 3xx / VIS 400 cameras with 7" displays

3169 J



Guidance Sleeve

for Wöhler mini camera head Ø 26 mm

3827 J

Guidance Sleeve with protection cage

for Wöhler mini camera head Ø 26 mm

3847 J

Wöhler Light Ring 26/40, detachable

for detachable Wöhler camera heads Ø 26 and Ø 40 mm

Light ring with 18 white LEDs, 53 mm outer Ø

8894 J

Guidance Set 100

for Wöhler camera head Ø 40 mm

protection sleeve with cut-out (art. 2641) , roller guide (art.3681) and centering brush

(art.3854)

4240 J

Protection Sleeve

for Wöhler camera head Ø 40 mm

with cut-out

2641 J

Wöhler Light Ring 26/40, detachable

for detachable Wöhler camera heads Ø 26 and Ø 40 mm

Light ring with 18 white LEDs 53 mm outer Ø

8894 J

Relining Adapter

for Wöhler VIS 3xx (only detachable version) and VIS 400 for reverse view

6888 J



Guidance Set 110

for Wöhler camera head Ø 51 mm

camera roller guide with protection cage (art.7826) and stabilization sleeve (art.3590)

3881 J

Guidance Set 150

for Wöhler camera head Ø 51 mm

Ø 20 cm guidance brush with protection cage (art. 3855), stabilization tube (art.21736), centering

brush (art.3854) and centering brush extension (art. 3853)

3882 J



Camera protection with brushes

for Wöhler pan&tilt camera head Ø 51 mm

with protection cage and 20 cm Ø brushes for centering

3855 J

Camera roller guide with protection cage

for Wöhler pan&tilt camera head Ø 51 mm

7826 J

Wöhler Supplementary Light

for Wöhler Camera Head Ø 51 mm

detachable

4194 J



Wöhler L 200 Locator (Receiver)

Wöhler L 200 Locator Receiver, plastic case, USB power supply with micro USB cable, grease

crayon (12 pcs. box, yellow), telescopic rod and headphones

7430 J

Components for all Wöhler VIS Camera Heads Article no.

Wöhler VIS Camera Trolley

Set

Wöhler VIS Camera Trolley, Camerahead-holder, Storage bag, Stabilization sleeve for light

ring 26/40 or Wöhler camera head Ø 51 mm, Stabilization sleeve for adaptation of push rods

with threaded connection M10

4753 J

Camera Spring Guide

for camera cables

prevents the camera head from turning and swinging inside the chimney

7092 J

Camera holder

for reverse view

for Wöhler VIS 3xx (only detachable version) and VIS 400

3720 J

Stabilization Sleeve

for Ø 51 mm camera head, for Wöhler camera heads Ø 40 mm in combination with light ring

(detachable). To stabilize the connection between camera push rod and camera head.

3590 J

Stabilization Sleeve

with M10 thread for connecting push rods

for Wöhler camera head Ø 51 mm, for Wöhler camera head Ø 40 mm in combination with light

ring (detachable), To stabilize the connection between camera push rod and camera head

3591 J

Guidance weight

740 g, stainless steel

to let down the camera head (e.g. in a chimney).

3857 J

Supplementary Light Ring

for Wöhler pan&tilt camera head Ø 51 mm, for Wöhler camera head Ø 26 mm and Wöhler

pan&tilt camera head Ø 40 mm in combination with guidance weight (art. 3857)

incl. battery pack with four AA batteries 1.5 V in cordura bag.

9377 J

Guidance Ball

for flex part of camera push rod,

improves ability to go through bends

3634 J

Centering Brush

Ø 20 cm

for all camera rods, can be fixed at any position of the camera rod

3854 J

Centering Brush Extension

Ø 20 cm

for Wöhler VIS 2xx and for Wöhler VIS 3xx / Wöhler VIS 400 (detachable versions)

to extend centering brush art. 3854

3853 J

VIS Spare Brushes

for centering brush, 24 pieces

3858 J

Stabilization Tube

for Wöhler VIS 2xx and for Wöhler VIS 3xx / Wöhler VIS 400 (detachable versions)

to connect centering brush (art. 3854) & extension (art. 3853)

21736 J

VIS Centering Brush

Ø 20 cm

for all camera rods, can be fixed directly behind the camera head

3850 J

Cleaning Sets Article no.

Wöhler VIS Cleaning Set Refill

1 liter disinfection spray, 50 cleaning tissues, 100 disposable gloves size XL (powder free),

200 ml lubricant, in plastic bag, for approx. 50 applications.

4726 O
