WOHLER VIS350plus Video Inspection Camera with Detachable Head

Description

WÖHLER VIS 300 & WÖHLER VIS 350

VIDEO INSPECTION, DOCUMENTATION, LEVEL INDICATOR, HOME FUNCTION AND LOCATOR WITH THE WÖHLER VIS 350

Video inspection in a case: With the new Wöhler VIS 350 Visual Inspection System, you not only have everything you need to inspect waste water pipes, flue gas and ventilation lines as well as industrial systems - you can also precisely locate the damage and accurately document the results of the inspection.

FUNCTIONALITY

·· CCS-image technology (Cristal Clear Screen)

·· Optics pan 360° and tilt 180° - ensure even the smallest

damage does not remain hidden from your view

·· Save pictures and videos on a 4 GB SD card (Wöhler VIS 350)

·· Camera head with integrated transmitter allowes

location by the Wöhler L 200 Locator

·· Digital level and angle of the camera head displayed on

the monitor

·· Home function automatically aligns the camera head to

a straight forward position - autolevel (Wöhler

VIS 350)

·· Brightly illuminating color camera head, 60 mm in length

and 40 mm in diameter, easily negotiates tight bends

·· Electronic meter counter displayed on the monitor

·· Bright TFT color monitor (tiltable and removable) supplies

razor sharp images

·· Battery operating time: 2 x 120 min. with 2 rechargeable

batteries (optional)

·· Fully equipped portable solution in a robust plastic case

WIDE RANGE OF APPLICATIONS

Analyze damage and inspect:

·· Waste water lines of Ø 70 mm and larger

·· House connections up to Ø 200 mm

·· Flue gas systems of Ø 60 mm and larger

·· Ductwork

·· False ceilings, hollow spaces, shafts

DOCUMENTATION

·· Simply record and save pictures and videos on a

4 GB SD card (Wöhler VIS 350) for documentation and

archiving purposes for you and your customers.

LOCATOR (OPTIONAL WITH WÖHLER L 200)

·· Transmitter integrated in camera head makes it possible

to precisely locate the camera head

·· Pinpoint damages in pipes for repair

·· Telescopic holder makes it possible to locate damage

under floors or in ceilings

·· Chalk holder with chalk to mark located damage immediately

·· Powerful rechargeable battery

TECHNICAL DATA

Monitor

Dimensions housing ....................176 x 114 x 32 mm

TFT-Display ..................................7" / 16:9 Format

Video-Out .....................................RCA-signal

Weight ...........................................400 g

Power Supply ...............................Space for 2 rechargeable batteries, each 12 V or via power pack

Battery operating time ................Max. 2 rechargeable batteries, each 120 mins. = 4 h

(battery status in display)

Pan&tilt Ø 40 mm color camera head

Typ .................................................1/3" COLOR CMOS

Pixels .............................................768 x 576 (PAL), 656 x 492 (NTSC)

Lens ..............................................f = 2.3 mm, F = 2.5

Viewing angle ...............................160°

Light source .................................12 white LEDs

Degree of protection ...................Waterproof according to IP 67

Dimensions ...................................Ø 40 mm x 60 mm

Operating temperature ................0...40 °C, RH 95 % MAX

Storage temperature ...................-20…50 °C, RH 95 % MAX

Push rod

Length ...........................................20 m or 30 m

Diameter .......................................6.5 mm

Plastic case

Dimensions ...................................51 x 43 x 17 cm (L x W x H)

Weight ...........................................8.2 kg

Distance Measurement

Wöhler VIS 300 / 350 ..................Digital meter counter

Accuracy .......................................± 5 %

Memory (Wöhler VIS 350)

Recording .....................................4 GB SD card (5 h recording capacity)

Interface ........................................Mini USB port

Locator transmitter

Transmission frequency ..............8.9 kHz

Locator Receiver

Display ..........................................Graphic visualization of transmitted position

Output impedance

Headphones .................................32 Ohm

Power supply ................................3.7 V Li-Ion rechargeable battery

Operating temperature ................0…40 °C

Storage temperature ...................-10 °C…40 °C

Weight ...........................................605 g

Dimensions ...................................32 x 14 x 7 cm (L x W x H)
