True universal power sensor for a vast number of applications
10 MHz to 18 GHz
-57 dBm to +33 dBm (2 nW to 2 W)
90 dB dynamic range for CW and modulated signals
Innovative three-path diode power sensor with enhanced inter-range performance
Continuous average, burst average, timeslot average, time gating and trace mode supported (video bandwidth 100 kHz)
Automatic burst detection and acquisition
Up to 1500 measurements/s (buffered mode)
Low sensitivity to harmonics
