Model	DS1054Z	DS1074Z	DS1074Z-S	DS1104Z	DS1104Z-S
Bandwidth	50 MHz	70 MHz		100 MHz
Analog Channels	4
Sample Rate	1GSa/s (Single-channel), 500MSa/s(Dual-channel), 250MSa/s(Fulll-channel)
Max Memory Depth	12Mpts(standard) ,24Mpts(option)
Max. Waveform Capture rate	Up to 30,000 wfms/s
Real Time waveform Record and Replay	Up to 60, 000 Frames(Opt.)
Std. Probes	RP2200 150MHz BW Passive Probe:4 sets
Built in 2 Ch Source		No	Yes	No	Yes

Accesorii standard

Power cord conforming to the standard of the country -

USB cable CB-USBA-USBB-FF-150

4 passive probes (150 MHz) RP2200

1 logic analyzer probe ( (MSO only)) RPL1116

Quick Guide -

Resource CD (include User"™s Guide and application software)

Optiuni recomandate

Optional Accessories

Rack Mount Kit RM-DS1000Z

Memory Depth Option

Analog channel: 24 Mpts (single-channel)/12 Mpts (dual-channel)/ 6 Mpts (four-channel)

Digital channel: 24 Mpts (8-channel)/12 Mpts (16-channel)

MEM-DS1000Z

Waveform Record Option The option supports waveform record and waveform playback REC-DS1000Z

Advanced Trigger Option The option includes these trigger functions: RS232/UART , I2C , SPI, Runt,

Windows, Nth edge, Delay, Timeout, Setup/Hold AT-DS1000Z

Serial Analysis Option The option includes RS232/UART, I2C and SPI trigger and decoding functions SA-DS1000Z
