High-speed USB 2.0 (480 Mbit/s)
Allows expansion up to 384 channels
Hot-swappable and auto-detectable characteristic minimizes startup time/effort
Internal and external 10 MHz reference clock
Mountable to rack with an optional rackmount kit
Simultaneous synchronization between modules
SSI/Star trigger bus synchronization between external trigger source and modules
Star trigger
External trigger-in and trigger-out signals
Temperature and fan speed monitoring
Compatible with Hi-Speed
USB 2.0 and USBTMC-USB488 standards
Bundled software - Agilent
Measurement Manager (AMM)

Alte produse KEYSIGHT

SURSA REGLABILA DE TENSIUNE 90/150W AGILENT U8001A U8002A

• Excellent regulation (0.01% + 2mV; 0.02% + 2mA)
• Fast 50µsec transient response
• Low output noise of 1mVrms and 3mArms from 20Hz to 20MHz

SOFTWARE DE ACHIZITIE AGILENT 34832A BENCHLINK DATA LOGGER PRO

• Quick test setup and execution
• Create multiple scan lists
• Execute different events based on predefined limits
• Use advanced math formulas
• Collect, monitor and manage data

MODUL PXI MULTIPLEXOR 64-CANALE 100V/1A AGILENT M9101A

• 64-channel, high-density 2-wire switch multiplexer
• 100Vrms
• 0.5A/1.0A switch/carry current
• 10W max power
• High-speed 500 usec reed relays
• Break-before-make or simultaneous switch closures

MODUL PXI MATRICE RF 3GHZ 1 X 16, 75 OHM AGILENT M9153A
