1000V Voltage Continuity Tester Metrel MD1050

• DC and AC voltage up to 600 V
• AC current measurement up to 600 A
• Resistance measurement
• Continuity test
• Diode test
• Frequency measurement
• Capacitance measurement



• Measurements on DC side of PV installation:
• Voltage, current, power, energy;
• Uoc (Open Circuit Voltage) and Isc (Short Circuit Current);
• I - U curve of PV modules and strings;
• Irradiance;
• Module temperature.
• Measurements on AC side of PV installation (power quality):
• Voltage, current, frequency, power, PF, energy, harmonics;
• Efficiency of PV module, inverter, PV system calculation.



• 1000V DC, 750V AC voltage measurement;
• 10A AC, DC current measurement;
• 250O..25MO Resistance measurement;
• 2500nF..25mF Capacitance measurement;
• 30Hz..200kHz Frequency Measurement
• Temperature measurement



• TRMS AC voltage and current measurement.
• Frequency measurement.
• Power: measures various power parameters (active, reactive, apparent power, THD, PF, phase displacement).
• Intelligent loss analysis: complex algorithms detect loss and allow determining possible reasons for current loss.
• Harmonics: measures current or voltage harmonic components and a percentage value of a harmonic up to the 49th.
• Total Harmonic Distortion (THD)
• Power Factor (PF).



• All tests on 3-phase electrical equipment can be carried out, including live leakage test, power, polarity, RCD and Active polarity.
• Simple connection to the PAT/MACHINE tester with automatic detection.
• Simple test procedures, identical to single phase equipment.
• Test sequence for 3-phase tests are automatically set, based on entered test codes and input voltages.



• insulation resistance,
• PE conductor continuity test,
• Line and Loop esistances with Fuse evaluation table built-in,
• RCD test with Trip lock function,
• phase sequence in 3-phase systems,
• on-line voltage monitor,
• 2-wire and 3-wire Earth resistance test with built-in battery operated generator,
• earth resistance test with Two Clamps method,
• Leakage Current test,
• test of Luminance with optional LUX meter probe



• DC insulation resistance,
• PE conductor continuity test,
• Line and Loop resistances with Fuse characteristics inside the instrument,
• RCD test with Trip lock function,
• phase sequence in 3-phase systems,
• on-line voltage monitor.



• Very large LCD display with bargraph and backlight
• High measuring range of up to 30 G? with test voltage from 50 V to 1000 V
• Fast and reliable continuity tests with automatic polarity reversal
• Voltage and frequency measurements
• Preprogrammed limits
• PASS/FAIL evaluation of result
• Bright GREEN/RED indicators provides visual evaluation of results
• Suited for testing on CAT IV installations



• Complete representation of a real low voltage installation in industrial and residential areas
• sockets,
• electrical loads,
• lightning,
• earthing systems for TT, TN and IT types of installations.
• 65 different measurements according to IEC/EN61557 are supported.
• Fault situation simulation switches can generate 19 errors or combination of these
• Detailed instruction manual with profound explanation of all typical measurements.



• meets overvoltage category CAT IV 1000 V
• TRMS AC, DC voltage measurement;
• TRMS AC, DC current measurement;
• Capacitance measurement;
• Resistance measurement;
• Diode test;
• Frequency measurement;
• Electric field detection;
• Continuity test (acoustic signaling);
• Temperature measurement.
