BLOCK DIAGRAMS	Input section Recording process section Playback process section Output section Noise reduction systems: Dolby© B and C Control system Servos Automatic Music Searc (AMS) Power supply Fluorescent visualiser
FAULT SIMULATOR	Allowing to simulate a hiogh number of regular faults.

Alte produse PROMAX

TRANSMITATOR CONVERTOR DVB-T -> FIBRA OPTICA PROMAX DT-610

• RF INPUT Frequency margin: From 470 to 862 MHz, From 50 to 1000 MHz(other options)
• FO OUTPUT Wavelength: 1550 ±20 nm (other wavelength as option)
• Fibre: 9/125, SMF28 or equivalent
• Connector: SC/APC
• optical links over distances up to 20 km

COMBINER 4 X DVB-T -> 1 X DVB-T PROMAX DT-722

• FREQUENCY MARGIN: From 50 MHz (C-2) to 860 MHz (C-69)
• INPUTS: 4 inputs Female BNC, 75 ? impedance
• RF OUTPUT: 1 female BNC output, 75 ? impedance
• output designed to mix output RF signals of COFDM modulators and transmodulators with DTT channels

GENERATOR SEMNAL VIDEO CABLU CATV PURTATOARE 4 CANALE 5..900 MHZ PROMAX RP-200

• 4 channels handheld pilot generator 5..900 MHz Frequency Range
• direct frequency band (downstream) and return band (upstream) in CATV
• fully-configurable by the user
• frequency and level of each pilot can be set independently
• powered by rechargeable batteries

TRANSMODULATOR DVB-S -> DVB-T PROMAX DT-202

• DVB-S FI INPUT: 2 independent DVB-S FI inputs
• RF OUTPUT: 2 combined DVB-T multiplexes
• PID Filtering with Filtering Table up to 32 PID
• Measurement: Bitrate of the output multiplex
• includes an internal combiner that delivers a single DVB-T output with high C/N

MODULATOR TDS-OFDM ASI/ SPI -> DTMB PROMAX MO-270

• compliant with China's national standard specification for digital terrestrial broadcasting GB20600-2006
• MPEG-2 TS INPUTS: 2x ASI, 1xSPI
• IF OUTPUT: 36 MHz, 50 ? BNC female connector
• RF OUTPUT: 45-875 MHz, 50 &8486; BNC female connector
• MODULATION: TDS-OFDM, 1 or 3780 subcarriers

TRANSMODULATOR SATELIT QPSK -> COFDM DVB-T PROMAX MO-162/163

• QPSK INPUT: 950 - 2150 MHz / -65 dBm to -25 dBm
• MPEG-2 TS INPUT: 2x DVB-ASI, 75 ? BNC female connector
• IF OUTPUT: Fixed at 36 MHz
• RF OUTPUT: 475 - 875 MHz (45 - 875 MHz for MO-163)

ANALIZOR IPTV MULTICAST SI UNICAST CU SUPORT SRT PROMAX ATLAS-IP

• ATLAS IP este un analizor IPTV multicast și unicast, cu suport pentru protocolul SRT și opțional ST 2110
• Include SD-SDI, HD-SDI și 3G-SDI prin RF (și, la cerere, prin fibră optică).

COMBINER 8 X DVB-T -> 1 X DVB-T PROMAX DT-710

• FREQUENCY MARGIN: From 50 MHz (C-2) to 860 MHz (C-69)
• INPUTS: 8 inputs Female BNC, 75 ? impedance
• RF OUTPUT: 1 female BNC output, 75 ? impedance
• output designed to mix output RF signals of COFDM modulators and transmodulators with DTT channels

ENCODER CUADRUPLU VIDEO/ AUDIO-> DVB-T/ TS-ASI PROMAX DT-504

• A/V INPUTS: 4 independent A/V inputs
• RF OUTPUT: 1 DVB-T multiplex
• TS-ASI OUTPUT: optional
• MPEG-2 ENCODER
• Video input: PAL/NTSC
• Audio input: Stereo/Mono/Dual/Joint Stereo

ENCODER VIDEO DVB HDTV H.264/AVC PROMAX EN-260

• H.264/AVC video encoding
• HDMI, YPbPr, composite video input interface
• MPEG-1 Audio Layer1 & Layer2 encoding
• TS over IP and TS-ASI outputs
• Ethernet remote control
