Tester Instalatii Electrice 250V-1000V Fluke 1652C

Cod: Fluke 1652C




Brosura produs PDF, 0.34 Mb

Descriere

  • Test voltage: 250V, 500V, 1000V
  • Two measurements at once and a dual display
  • PEFC/PSC and loop impedance are measured and displayed in parallel, saves you more than 50% of test time compared to other loop testers.
  • Additional new high current loop mode
  • Faster measurements compared to loop tests with non-trip mode for RCD’s
  • Unique zero adapter for fast, always reliable and accurate test lead and mains cord compensation
  • Fast voltage measurement between L-N, L-PE and N-PE using the mains cord. No need to change measurement connections
  • Earth Volt Touchpad detects raised earth voltages >50 V, indicating potential dangerous situations
  • Supplied with the SureGrip™ test leads and clips which gives the user a comfortable, reliable grip
  • Rotary dial knob indicates clear which function is selected, all functionalities on one spot and no complex multi level menus
  • Large display with backlight, clear symbols and exceptionally wide viewing angle for easy and safe readings
  • PASS/FAIL indication for RCD test results
  • Variable RCD current mode for customized settings
  • Rugged & lightweight Withstands a drop of 1 meter


Accesorii standard

  • 6 AA Cell batteries
  • C1600 Hard carrying case
  • Zero Adapter
  • Mains test cord
  • TL165X/STD Standard Test Lead Set
  • Padded carrying strap
  • Quick reference guide
  • TP165X Remote control probe and lead
  • Users manual on CD-ROM


Optiuni recomandate

  • ES165X Earth Spike Test Kit (Fluke 1653)
  • TP165X Remote Control Probe
  • DMS DMS Software
  • FlukeView Forms FlukeView Forms Software with cable
