Calibrator de presiune Fluke 719Pro cu pompa integrata

Cod: Fluke 719Pro 719Pro-30G 719Pro-150G 719Pro-300G




Brosura produs PDF, 1.05 Mb

Descriere

Fluke 719Pro-30G Electric Pressure Calibrator



The 719Pro includes a full functioning loop calibrator that sources, simulates and measures mA signals and more making it the ideal test tool for calibrating high accuracy transmitters, pressure switches and pressure gauges.

Get the ultimate in measurement flexibility with the large backlit screen, which displays three parameters at once:

•                     Pressure measurement from internal or external sensor

•                     Sourced/simulated or measured mA values

•                     Temperature measured by optional RTD probe





  • Unique integrated electric pump for one handed pressure calibration
  • Test pressure switches easily with easy-to-use switch test function
  • Precision pressure adjust vernier for easy and accurate pressure calibration
  • Ideal accuracy and performance (0.025 %) for reference class transmitter calibration
  • 30 PSI, 150 PSI and 300 PSI pressure ranges
  • Programmable pressure calibrator pump limit:
    • Eliminates over-pressurization
    • Allows the user to program target pressures for pumping
  • Extended pressure measurement range with any of 29 700Pxx Pressure Modules
  • Pump cleanout ports reduce pump failures from moisture and fluid damage
  • Fluid trap included with the unit to mitigate chance of fluid damage in at-risk applications
  • Precision temperature measurement with optional RTD probe





Fluke-719Pro-30G -12 to 30 PSI /-0.8 to 2 bar, 0.001 PSI/ 0.0001 bar Resolution

Fluke-719Pro-150G -12 to 150 PSI /-0.8 to 10 bar, 0.01 PSI/0.001 bar Resolution

Fluke-719Pro-300G -12 to 300 PSI / -0.8 to 20 bar, 0.01 PSI/0.001 bar Resolution

Accuracy: ± 0.025 % of full scale, 6 months; ± 0.035 % of full scale, 1 year

Dry Air and non-corrosive gas only







Accesorii standard

Ordering information

Fluke-719Pro-30G Electric Pressure Calibrator, 30 PSIG

Fluke-719Pro-150G Electric Pressure Calibrator, 150 PSIG

Fluke-719Pro-300G Electric Pressure Calibrator, 300 PSIG

Fluke-720RTD RTD Probe for 721 and 719Pro

Fluke-720URTDA Universal RTD adapter for Fluke-721 and 719Pro

Fluke-71XTrap Liquid and dirt trap for 718 and 719Pro



Included with all models

•                     Test leads with alligator clips

•                     printed users manual and users manual on CD-ROM in 14 languages

•                     fluid trap

•                     carrying case

•                     1/4 inch NPT to ¼ inch ISO adapter

•                     accessory hose kit with (2) 1/8 inch quick fit adapters and 1 meter of hose

•                     Traceable Certificate of Calibration







Optiuni recomandate

Fluke-720RTD RTD Probe for 721 and 719Pro

Fluke-720URTDA Universal RTD adapter for Fluke-721 and 719Pro

Fluke-71XTrap Liquid and dirt trap for 718 and 719Pro
