Analizor de spectru modular controlat la distanta 10MHz..6GHz Aaronia Spectran HF RSA6000

Cod: Aaronia Spectran HF RSA6000

Brosura produs

PDF, 1.35 Mb

Descriere

Frequency range: 10MHz to 6GHz
DANL: -135dBm(1Hz)
DANL with Preamp: -150dBm(1Hz)
Max. power at RF input: +10dBm
Lowest sample time: 10mS
Resolution (RBW): 3kHz to 50MHz
Units: dBm, dBµV, V/m, A/m, W/m², dBµV/m, W/cm² etc.
Detectors: RMS, Min/Max
Demodulator: AM, FM
Input: 50 Ohm N, RF-input (f)
Accuracy: +/- 2dB (typ.)
Interface: USB 2.0/1.1/LAN
Dimensions (L/W/D): 19 inch rack mount
Weight: 3450gr
Warranty: 2 years

Integrated PC:

CPU: Intel Celeron G530 2,4GHz
RAM: 2x2GB SO-DiMM DDR3, 1066MHz
HDD: 320GB (5400rpm)
External Ports: 2x USB 2.0, 2x USB 3.0, 1x Audio, 1x 10/100/1000 Mb/s Ethernet, 1x DVI-I (Analog,Digital), 1x HDMI, 1x eSATA
Power supply: 19,5V (7,9A max.)
Operatingsystem: Linux

Highlights:

Exposure limit calculation and display according to DIN/VDE 0848
Up to 100x faster sample time as V3 units
Up to 60dB higher sensitivity as V3 units
Low noise preamplifier (option)
14Bit Dual-ADC
DDC Hardware-Filter
150 MIPS DSP (CPU)
Real-time remote control via USB /LAN
Vector (I/Q) measurement
Real-time Peak Power Detector (option)
Audio out for the use of PC based FFT analyzer software
Very thick (3mm) aluminium housing offering very good screening.
Free MAC OS, Linux and Windows software

Examples for possible analysis and measurements within frequency range (10MHz - 6GHz):

Radio & TV
Tetra/BOS
ISM434
LTE800
ISM868
GSM900
GSM1800
GSM1900
DECT
UMTS
WLAN
Microwave
Bluetooth
WiFi
LTE2.6
WiMAX
Directional Radio
5GHz WLAN
etc.

Accesorii standard

Remote Spectrum Analyzer HF RSA 6000
Power supply incl. international adapter set
Cleaning brush
Detailed English manual (on CD)
Analyzer software for MAC OS, Linux and Windows (on CD)
