Seba KMT vLocCam2 Location system for location and depth measurement of Sewer TV Cameras

• Powerful 0.1 Hz VLF test system
• High test power without frequency reduction
• No polarisation effects as by DC testing
• Protocoling
• Breakdown recognition
• Leakage current measurement



• »» DC-testing up to 32 kV
• »» Prelocating
• - Reflection measurement
• - ARM measurement
• (Arc Reflection Method) up to 32 kV
• - Decay up to 32 kV
• - ICE Impulse Current Method
• 0…4 / 8 / 16 / 32 kV
• »» Burning (fault conditioning) up to 32 kV
• »» Cable tracing (optional)
• »» Pinpointing
• - Distance and acoustic measurement
• 0 … 8 / 16 / 32 kV at 1750 J



• Range 8 km, 64 km (for ICE and Decay only)
• Fully equipped reflectometer with cursor, gain, and range adjustment
• High-contrast 5.7’’ TFT color display (640 x 480 pixel), with LED backlight
• Single-phase ARM input with ICE, Decay and Trigger
• AC or battery operated (up to 3 hours battery life)



• Test range 50 m ... 15000 m
• High local resolution of 5 cm in 50 m test range
• Simple operation due to menu prompting and help functions
• Easy evaluation of the traces by simultaneous display of zoom and total view (split-screen)
• Large display with backlight
• Individual measurement, continuous measurement and averaging
• Measuring connections suitable for live voltage up to 250 V



• PD diagnosis under oscillating wave test voltage
• PD evaluation possibility and pattern recognition at the nominal voltage level
• Automatic Calibration and Joint location facility
• PD level measurement according to IEC 270 at a bandwidth of 150 ... 650 kHz
• Semi- and fully automatic PD analysing software for defect location with mapping feature
• Calculation of the cable capacitance and the tan delta value
• Simple to use and easy to handle menu-driven unit for operation of the test sequence
• Compact design; low weight



• available in three versions: 50kV 80kV 110kV DC
• Highest safety by monitoring functions and easy operation
• Quick and easy mounting with compact and simple setup
• Meeting individual needs by modular design



• Fault location on live low voltage cables
• 3 phase cable monitor for a permanent check of current and voltage
• GSM remote controlled system



• Voltage Ranges : 0.. 8kV / 0..16kV / 0..32kV
• SWG 1750C with 8 - 16 - 32 kV / 1750 J
• SWG 1750 CI with 8 - 16 - 32 kV / 1750 J, incl. leakage current measurement
• SWG 1750 C-4 with 2 - 4 kV / 1150 J and 8 - 16 - 32 kV / 1750 J
• SWG 1750 CD with 8 - 16 - 32 kV / 3500 J



• Clearly laid out user interface
• Automatic or manual amplification options
• Depth and amperage at the press of a button
• Distance Sensitive Left/Right GuidanceTM
• Sheath fault location (optional)



• Directional compass for fast and precise location of camera heads or sondes
• Continuous depth measurement
• Passive frequencies (current and radio signal) to prevent cable damage
• Sunlight-compatible colour display
