Seba KMT Vivax Metrotech vLoc2 Line Location and Tracer for Underground Pipes and Cables

Code: Seba-KMT Vivax vLoc2



Datasheet PDF, 1.87 Mb


Description

vLocPro2

Vivax vLocPro - location technology to meet high standards

The development of the vLocPro enables you to perform your daily location tasks faster and with greater precision, and it offers unbeatable value for money.

The large colour display, which can also be read in the strongest sunlight, provides the user with all the important information at a glance. Even unpracticed users can intuitively learn how to operate the entire location system, thus keeping training requirments to a minimum. A wide frequency spectrum - compatible with all conventional location systems on the market - enables the user to select the optimal frequency for every task and thus optimise the location results. The factory settings for the frequencies can be modified or changed at any time. Additional frequency packages are available free of charge.





  • Carbon-reinforced plastic housing
  • Protection class IP 54 for use in any weather conditions
  • Colour display
  • High-speed processor
  • Several location modes with orientation using a compass
  • A large number of available frequencies
  • Depth/amperage at the press of a button or sustained
  • Normal and modulated audio modes(separately selectable for the operating modes "current", "radio" and "active")
  • Signal direction (SD) for improved reliability in locating
  • Optional "time-off" function
  • Rechargeable and alkaline batteries
  • Optional accessories (see reverse side)


Standard accessories





Recommended options





More products SEBAKMT

SEBA KMT VFL CR-60-HP LONG CABLES TEST SYSTEMS

• Very high test power without frequency reduction
• Covers cables up to 20 km @ maximum Voltage
• No polarisation effects as with DC
• Protocoling
• Breakdown detection
• Leakage current measurement
• Powerful 0.1 Hz VLF test system with energy recovery


SEBA T18/5 SURGE WAVE VOLTAGE GENERATOR FOR CABLE FAULT LOCATING

• Voltage Ranges : 0..3kV / 0..6kV / 0..12kV
• Energy : 1000 Joules

SEBA KMT VLOCML2 PIPELINE LOCATION AND TRACING FOR UNDERGROUND PIPES AND CABLES

• Location of passive markers which are used by utility
• companies for labelling underground lines
• Colour-coded display of the signal strength
• Specifi c line location mode
• Specifi c marker location mode
• Mode for simultaneous location of lines and markers


SEBA DIGIPHONE+ ESG NT PINPOINTING ACOUSTIC PINPOINTING SET FOR STEATH FAULT LOCATION IN UNDERGROUND CABLES

• Perfect acoustic quality and noise immunity
• Automatic filtration of interfering signals
• Automatic zero calibration, no adjustments necessary
• History mode
• Acoustic and step voltage fault location in one device
• BNR technology for perfect acoustic quality and noise immunity
• Automatic filtration of interfering signals
• Automatic setting of all parameters, no adjustments necessary


SEBA KMT VFL CR-28..60 VLF TEST SYSTEMS FOR MEDIUM VOLTAGE CABLE TESTING

• VLF CR-28 up to cable series 15 kV
• VLF CR-40 up to cable series 23 kV
• VLF CR-60 up to cable series 35 kV
• VLF, DC and sheath fault testing in one device
• Portable thanks to two-part construction
• High test capacitance
• Integrated discharge system
• Reporting


SEBA KMT LPD MONITOR ON-LINE PD PARTIAL DISCHARGE MONITORING SYSTEM FOR MV AND HV

• Portable online PD measuring system for monitoring MV and HV systems
•  16 channels
•  Allows ef? cient forward planning of necessary maintenance work
•  Quick and easy to install
•  Integrated automatic knowledge-based evaluation of measured PD levels
•  Current status can be viewed at any time via remote access


SEBA KMT OWTS M60 DIELECTRIC DIAGNOSIS AND PARTIAL DISCHARGE MEASURING SYSTEM

• PD diagnosis under oscillating wave test voltage
• PD evaluation possibility and pattern recognition at the nominal voltage level
• Automatic Calibration and Joint location facility
• PD level measurement according to IEC 270 at a bandwidth of 150 ... 650 kHz
• Semi- and fully automatic PD analysing software for defect location with mapping feature
• Calculation of the cable capacitance and the tan delta value
• Simple to use and easy to handle menu-driven unit for operation of the test sequence
• Compact design; low weight


SEBA DIGIPHONE+ SURGE WAVE RECEIVER FOR ACOUSTIC AND ELECTROMAGNETIC FAULT PINPOINTING IN CABLES

• Perfect acoustic quality and noise immunity
• Automatic mute function to protect your ears
• Bright, transflective sun readable display
• Easiest handling with automatic adjustment
• Earphone volume limitation to 84 dB(A)


SEBA SURGEFLEX SFX-40 SPG-40 CABLE FAULT LOCATING SYSTEM

• DC Testing up to 40 kV ARM, ICE and Decay Method integrated
• Operation by VGA Display and single button rotary encoder
• High surge energy fort he acoustic pinpointing 1000 or 2000 J
• Surge voltage levels for MV cablel 0 ... 12,5/25 kV or 0 ... 16/32 kV
• Surge voltage levels for lower voltage 0 ... 3/6 kV or 0 ... 4/8 kV
• Integrated safety system


SEBA SURGEFLEX SFX-32 SPG-32 CABLE FAULT LOCATING SYSTEM

• »» DC-testing up to 32 kV
• »» Prelocating
• - Reflection measurement
• - ARM measurement
• (Arc Reflection Method) up to 32 kV
• - Decay up to 32 kV
• - ICE Impulse Current Method
• 0…4 / 8 / 16 / 32 kV
• »» Burning (fault conditioning) up to 32 kV
• »» Cable tracing (optional)
• »» Pinpointing
• - Distance and acoustic measurement
• 0 … 8 / 16 / 32 kV at 1750 J
