• Home network control in liaison with Embedded PXA 255/270/272/320
• Power line communication and ZigBee modules with Multi Port in use together
• Embedded



• The optional Embedded System(ED-255EK) can be linked as a gateway
• ZigBee network can be built using TinyOS, F8WOS
• Capable of control and monitor through Ethernet
• The RFID Card Reader is supplied as a standard shipped component for applied experiments on security, home automation and robot



• The electronic manual operable on PC comes with ED-1450 and e-learning is optimized by remote control of student’s operating program and evaluation of student’s online report in real time.
• Through DS-1410, it provides Variable Power Supply(VPS), Function Generator(FG), Analog Output, Digital Output needed for experiments.



• Various types of test point for Air-interface experiments
• Anti-collision function
• OCX Library useful for application engineers
• 13.56MHz I-CODE Type in common usage
• Capability of reading and writing data on Tag



• F/W program practices for RFID Reader
• 13.56MHz and 900MHz in common use
• Data Read/Write to 900MHz Tag
• ED-3710 application programming (13.56MHz, 900MHz)
• Fixed Type RFID Reader



• Panel type structure for good grasp of entire network configuration
• Learning about the functions and characteristics of basic network equipments such as NIC, HUB, Router and DSU, plus installation and maintenance
• Interlocking experiments with Internet for clear understanding a real network
• Capable of conneting to the open network on campus



• Study of functions, characteristics, installation, repair and maintenance of basic ADSL components such as Telephone Exchange, Splitter, DSLAM, ADSL Modem, HUB and LAN Card
• Network structure through interworking experiments with Internet and capability of Internet usage and simple programming
• Capable of interworking experiments with ED-NET-3(LAN Training System)



• Step by step courses on the networks theories to train the engineers
• CISCO Router based training will help obtain CCNA, CCNP, CCIE certificates
• Functions and characteristics of network system(LAN Card, Router, L2 Switching Hub, L3 Switching Hub)
• 19Rack type structure for effective network configuration
• Optimized learning system for the Router based on one on one training(OPTION)



• Rich experiments devoted to IS95 standard
• Easy-to-follow structure as main functions are itemized in modules



• The Electronic Manual operable on PC comes with ED-1440 and e-learning is optimized by remote control of student’s operating program and evaluation of student’s online peport in real time.
• Through DS-1410, it provides Variable Power Supply(VPS), Function Generator(FG), Analog Output, Digital Output needed for experiments.



• Interlocking system package with CBIS-1400 and DS-1410 Models (Options)
• Experiments on a measurable low frequency bandwidth
• Realistic experiments on modulation and demodulation
• Verification of the output waveform on PC engaged with CBIS-1400 Model



• Modularized by each communicarion type
• PAM, PTM, PCM, DPCM, ADPCM, LDM, ADM, Delta-sigma
• No need to have additional generators (built-in power supply and signal source)
• Can display the test point and measure signals using an oscilloscope



• 10 experimental modules with a mainframe console
• Basic concepts on the communication systems
• Experiments on the broadcast frequency band tuning
• Generation of AM and FM waves and detection theory



• 7 experimental modules with a mainframe console
• Harmonic Analysis and Superheterodyne Receiver experiments
• PCM(TDM), Sample Hold, and Delta Modulation experiments



• Modularized by the function of digital communication circuits
• FSK, ASK, PSK, QPSK and digital communication principles
• 12 types of modules including a power supply unit



• E/O and O/E conversion and characteristics
• Optical PCM communication(trasmission&reception)
• Optical Data communications using personal computer
• DC power supply, a roll of fiber cable and the microphone included as peripherals



• PLL and Digital Synthesizer
• PAM, PCM, FDM and FSK Modem
• 10types of module including DC Power Supply



• Gunn Oscillator base system
• Directional Coupler & Horn Antenna
• Frequency : 9GHz~11GHz (X-Band)
• Microwave output : 15mV



• 16 different types of Antenna
• RF source generation : 500MHz, 2GHz and 10GHz
• Software simulation of radiation Patterns and characteristics of Antenna
• Antenna Directional Coupler (Manual / Remote)



• Helps understand theories on the Microstrip Line Theory and Microwave Elements Design
• Composed of 22 types of modules such as VCO using Coupler, Divider, Circulator, Attenuator and Filter
• SWR Detector, Modulation, Transmission/Reception, Detector, Self-Oscillation functions
