Sonda pasiva osciloscop atenuare 1x Testec TT-MF100

• I-prober 520 - PCB track Touch & Measure
• Current measurement from insulated probing of conductor
• Suitable for observation and measurement of current in PCB tracks, component leads and ground planes
• Wide dynamic range of 10mA to 20A peak to peak
• Wide bandwidth of DC to 5MHz
• Low noise figure equivalent to <6mA rms at full B/W



• TT-AP 1300 x10, DC..1.3GHz
• Bandwidth: DC 1,3GHz
• Attenuation Ratio: x10
• Rise Time: <0,25ns

• TT-SI 200 1:10, 200MHz
• Bandwidth: 200MHz
• Attenuation Ratio: : x10
• Accuracy: ± 1%
• Rise Time: 1,75ns
• Input Impedance: 500kW / 7pF

• TT-LF 312 1:1/10:1 - 1,2m, 15MHz/150MHz
• TT-LF 316 1:1/10:1 - 1,6m, 12MHz/130MHz
• TT-LF 320 1:1/10:1 - 2,0m, 10MHz/100MHz

• TT-HVP 40 1000:1, 300Hz
• Attenuation Ratio: x1000 @ 10 Ω, x2000 @ 1 Ω
• Input Impedance: 1000 Ω
• Bandwidth: 300 Hz (-3dB)
• Max. Input Voltage: DC 40kV, AC 28kVrms (0..300Hz)
• Cable Length: 1,0 m

• TT-SI 9010 1:100 / 1:1000, 70MHz
• TT-SI 9010A 1:100 / 1:1000, 70MHz

• TT-MF 112 1:1 - 1,2m, 30MHz
• TT-MF 116 1:1 - 1,6m, 27MHz
• TT-MF 120 1:1 - 2,0m, 25MHz

• TT-LF 212 10:1 - 1,2m, 150MHz
• TT-LF 216 10:1 - 1,6m, 130MHz
• TT-LF 220 10:1 - 2,0m, 100MHz

• TT-MF 312 1:1/10:1 1,2m, 20MHz/250MHz
• TT-MF 316 1:1/10:1 - 1,6m, 13MHz/220MHz
• TT-MF 320 1:1/10:1 - 2,0m, 10MHz/190MHz

• TT-22100 Cable Length: 100cm, Connector: 2x 4mm Plug
• TT-22110 Max. Current: 2A, Connector: BNC-Plug
