Electrician's Multimeter Megger - AVO410

• Most advanced primary current injection test system to simplify all types of switchgear and CT commissioning, ground grid, circuit breaker testing and more
• Modular design to permit optimal user configuration of output current vs. unit size
• Compact transport cart facilitates portability into switchgear rooms with limited space
• Unique I/30 function allows the current to be pre-set using low current to prevent test sample heating, thus eliminating corruption of test result



• Test voltages : 60 kV, 80 kV and 100 kV
• Laboratory instruments for measuring insulating oil breakdown voltage
• Lock in precision - oil vessel with lockable adjustment
• Bright 3.5" colour display
• Suitable for mineral, ester and silicon oils
• Trip detection circuit with direct measurement of voltage and current
• Ultra fast (< 10 µs) HV switch off time



• 2000 count digital display
• 1000 V DC / 750 V AC ranges
• 10 A AC / DC ranges
• Resistance, frequency and capacitance ranges



• The only one that fully tests your instruments to the regs.
• Tests the full range of your tester½s capability not just what½s easy
• Won½t trip RCD protected circuits
• Checks insulation, continuity, loop and RCD functions of testers
• Works with all testers for Part P Certification



• Stand-alone or remote-control operation
• Accurately measures ratio, phase deviation and excitation current
• Field upgradeable without compromise to calibration
• Built-in capability for storing and downloading test results in an XML format, via RS-232, Ethernet or USB ports (depending on model)
• Works in the presence of high interference/high voltage
• Highest ratio measurement (45,000:1); highest accuracy (0.1%)
• Displays % error vs. name plate with pass/fail limits



• Reliable and stable a.c. and d.c. power supply for circuit breaker testing
• Continuously variable 24-250 V AC or DC output
• Separate outputs for close coil, trip coil and spring charging motor voltage
• Direct triggering for minimum trip voltage testing



• TDR20000/2P can perform single or dual channel measurements on a wide range of metallic cables
• dead or Live cables to CATIII 300V Phase to earth or 415V phase to phase can be tested.



• 6000 count backlit digital display
• True RMS reading on a.c. mode
• 1000 V d.c. / 750 V a.c. ranges
• 10 A a.c. / d.c. ranges



• Alimentat de la tensiunea fazei A AC/DC
• Rezistent la intemperii conform standardului IP54 pentru utilizare în orice mediu
• Interval 1000 VAC şi 1500 VDC
• Auto CT identifică curentul la care este conectat instrumentul şi intervalul în care se află
• Oscilloscop şi DVM în timp real
• Conformitate IEC61000-4-30 Clasa A



• Capable of testing electromechanical or thermal-magnetic trip devices with dc current
• Digital timer
• High-current output up to 30,000 amperes
