Surse reglabile programabile 80-200W Agilent E363xA

• 100 MHz bandwidth
• 2 GSa/s sample rate
• 2 analog plus 16 digital channels
• Standard 8 Mpts MegaZoom III deep memory



• RF switching to 3 GHz
• Dual 1x4 50 ohm RF switch multiplexer to 3GHz
• Off channel termination
• 30V, 1A, 1W switching
• 60 dB isolation at 1 GHz



• 1 mHz to 80 MHz
• 1 or 2 Channels(order 2 x 81105A modules)
• 3 ns to 200 ms variable transition time
• Up to 10 Vpp into 50 O (20 Vpp into open circuit)



• Cable and Antenna Analyzer - 2 MHz to 4/ 6 GH
• Network Analyzer - 2 MHz to 4/ 6 GHz, S11 and S21
• Spectrum Analyzer - 5 kHz to 4/ 6 GHz
• Interference Analyzer - 5 kHz to 4/ 6 GHz Spectrogram
• Power Meter - 9 kHz to 24 GHz
• Vector Voltmeter - 2 MHz to 4/ 6 GHz



• 4-slot mainframe holds up to 600 W of total power and up to 4 modules
• Voltmeter and Ammeter functions
• Arbitrary waveform generator function
• Oscilloscope function
• Data logger function



• Three SPDT unterminated switches
• 4 GHz, 20 GHz or 26.6 GHz options
• High isolation loss, low VSWR
• Up to 50W switching



• High-speed USB 2.0
• 16-bit resolution
• 64 SE/32 DI multiplex analog input channels
• Up to 250 kSa/s sampling rate
• 2 12-bit analog output channels,
• 1 MSa/s analog output update rate
• 24-bit programmable TTL input/output channels



• 250 kHz to 20 GHz, 31.8 GHz, 40 GHz, 50 GHz or 67 GHz operational to 70 GHz
• 0.001 Hz resolution
• +23 dBm @ 20 GHz, +17dBm @ 40 GHz, +14 dBm @ 67 GHz output power (typ); > +30 dBm (typ) with Option 521.
• AM, FM, ØM, pulse, and scan
• Extendable to 75, 90, 110, 140, 170, 220, 325, or 500 GHz



• High speed USB 2.0 (480MBit/s)
• 16-bit resolution
• simultaneous analog input channels
• up to 500 kSa/s/ch
• 2 12-bit analog output channels
• 1 MSa/s analog output update rate
• 24-bit programmable TTL input/output channels



• 1 µHz - 330 MHz pulse generation with variable rise/fall time
• 1 µHz - 500 MHz sine waveform output
• 14-bit, 2.5 GSa/s arbitrary waveforms
• 1 or 2 channel, coupled and uncoupled
