Generator semnal RF 250 kHz..3 GHz sau 6 GHz Agilent E4428C ESG

Cod: Agilent E4428C ESG




Brosura produs PDF, 0.82 Mb

Descriere

  • 250 kHz to 3 GHz or 6 GHz
  • 0.01 Hz resolution
  • -136 to 17 dBm @ 1 GHZ and 10 dBm @ 6 GHz output power
  • AM, FM, ØM, and pulse modulation
  • +/-0.5 to +/-0.9 dB level accuracy (> -110 dBm)
  • -134 dBc/Hz SSB phase noise @ 20 kHz offset, 1 GHz carrier (typ)
  • Enhanced phase noise performance (Option UNJ) ships standard
  • High-stability timebase: oven-controlled crystal oscillator (OXCO)
  • DC to 10 MHz FM modulation rates, maximum deviations up to 8 MHz
  • Dual internal function generators: sine, square, ramp, triangle, noise, DC, pulse, swept sine, dual sine
  • Step and list sweep (frequency and power)
  • 10BaseT LAN and GPIB
  • SCPI and IVI-COM drivers
  • Backwards compatible with all ESG signal generators


Optiuni recomandate

  • 503  250 kHz to 3 GHz [electronic attenuator standard]
  • 506 250 kHz to 6 GHz [mechanical attenuator only]
