Extech 42275 Datalogger TEmperatura-Umiditate cu interfata PC

Cod: Extech 42275




Brosura produs PDF, 0.37 Mb

Descriere

Temperature/Humidity datalogger with docking station and PC software

The 42275 is a Temperature/Humidity Datalogger Kit with PC Interface. This waterproof (IP65) datalogger records up to 16,000 readings (8,000 readings for each parameter) with a date/time stamp that can be downloaded to your PC for analysis. Temperature/Humidity can be viewed on the datalogger's LCD display. Data can be downloaded from a docking station, which can add additional loggers. Programmable sampling rate from 1sec to 2hrs plus Hi/Lo limits with alarm indication. Product comes complete with docking station, software, and one 42270 datalogger with Li-Ion battery.



Features:

·         Wide operating temperature range: -40°F to 185°F (-40°C to 85°C)

·         Humidity range: 0 to 100% RH

·         Records up to 16,000 readings (8,000 readings for each parameter)

·         Use in storage containers, shipping vans, freezers and more

·         Logs data for days, weeks or months - up to 1 year battery life

·         Multiple 42270 dataloggers can be programmed and data downloaded from one single docking station

·         Programmable sampling rate from 1sec to 12hrs plus Hi/Lo limits with alarm indication

·         Program the logger, analyze and store data using Windows® compatible software

·         View current temperature/humidity on Datalogger's LCD display

·         Three start methods: Scheduled, immediate or magnetic

·         Includes USB docking station with cable, 42270 Humidity/Temperature datalogger and PC software
