Lon Device Development KIT ED-5960

• Consists of one gripper and 5-axis vertical multi joints
• Absolute-type RVDT Position Sensor applied to each axis and requires no Limit switch
• High performance CPU enables real-time control of each axis
• PID gain tuning and real-time control



• Comprehensive experiments on PLC, Inverter, Touch Panel and Sensor
• Various programming experiments including digital numeric value
• Aluminum case structure for convenient storage and mobility
• Built-in DC power supply as part of system for handy practices
• All-in-one training system which comes with the inverter and touch panel



• SCR characteristics
• Rectifier and phase control
• Trigger and gate control
• Motor speed control



• PC-based multi-function instrument for electricity/electronics and other experiments
• Digital Storage Oscilloscope with the 2-channel simultaneous 50MS/s sampling rate
• Spectrum Analyzer functions using Digital Storage Oscilloscope(DSO)
• Variable Power Supply(VPS), Function Generator(FG), Analog Output and Digital Output
• Analysis of collected data on PC through the modules of DSO, DMM, FC and Analog/Digital Input
• Numerical and graphical indication of the data measured and analyzed in real time



• The Electronic Manual operable on PC comes with ED-1440 and e-learning is optimized by remote control of student’s operating program and evaluation of student’s online peport in real time.
• Through DS-1410, it provides Variable Power Supply(VPS), Function Generator(FG), Analog Output, Digital Output needed for experiments.



• 24 Experimental Boards in two sections : (A) Semiconductor and (B) Electronic Circuit
• Experimental Board rack and board storage cabinet



• 19 types of modules & graphic boards
• 25 types of electrical machine assembly
• Experimental board rack & storage trolley



• Experiments on various types of special control unit
• Characteristics of Servo Motor and setup of Servo Driver
• Essential components in automation using a PLC position module
• 4mm banana jack to increase wiring capability



• Convenient parts fixation by ‘one-touch lever’ bases and aluminum profile structure
• Efficient space utilization by mounting parts horizontally/vertically
• 41 transparent hydraulic and electrical/electronic parts plus various optional components.
• Various hydraulic devices and components for Flexible Manufacturing System



• Complete Motor/Generator Training System
• Various load characteristics(Resistance, L/C Reactance and Torque)
• Selectable System(ED-5100-1, ED-5100-2, ED-5100-3 or Full Set)
