Pressure Range	Type	Accuracy
-1 ~0 bar 0~0.7bar 0~1bar 0~2bar 0~7bar 0~20bar 0~30bar 0~70bar	G	0.05%FS
0~140bar 0~200bar 0~300bar	SG	0.05%FS
0~700bar	SG	0.05%FS
-1 ~0 bar 0~0.7bar 0~1bar	A	0.02%FS
0~2bar 0~7bar 0~20bar 0~30bar 0~70bar 0~140bar 0~200bar 0~300bar 0~700bar	A	0.05%FS

Remark:

G: Gauge pressure

SG:sealed gauge pressure

A: absolute pressure

The other pressure ranges can be customized

Accesorii standard

Optiuni recomandate

Alte produse CONST

Brand: ConST

POMPA CALIBRARE PRESIUNI JOASE 0..&PLUSMN;0.4 BAR CONST113

• Pressure: 0~ ±0.4 bar
• Pressure resolution: 0.0001mbar (0.01Pa)
• Size: 230mm * 130mm * 125 mm Weight:1.0 kg
• low air pressure source with the ability to easily adjust and stabilize

Brand: ConST

POMPA HIDRAULICA CALIBRARE PRESIUNI -90%~ 700 BAR CONST182

• Pressure: -90%~ 700 bar
• Water media
• Dual pressure ranges
• User friendly, easy to get 700bar high pressure
• Minimum leakage and very high pressure stability.

Brand: ConST

SOLUTIE ON-SITE CALIBRARE PNEUMATICA PRESIUNE CONST

• portable gauge and transmitter calibration system that is very conveniently use on-site
• compact, easily operation, reduces calculations errors and has a 0.02% full scales accuracy
• up to 370 PSI (25 bar)
• weather-proof kitbag that can protect instruments well

Brand: ConST

CALIBRATOR DE PROCES MULTIFUNCTIONAL CONST317

• Multifunction Process Calibrator
• Measure: mV, V, mA, Hz, Pulse, O, on-off, RC*4, RTD*8
• Source: mV, V, mA, Hz, Pulse, O, on-off, RC*4, RTD*8
• Task Management, Ramp, Step, 24V loop power source
• Connect to external pressure modules

Brand: ConST

CALIBRATOR DE TEMPERATURA MULTIFUNCTIONAL PORTABIL CONST316

• Multifunction Temperature Calibrator
• Measure: mV, V, mA, Hz, Pulse, O, on-off, RC*4, RTD*8
• Source: mV, V, mA, Hz, Pulse, O, on-off, RC*4, RTD*8
• Task Management
• Ramp, Step
• 24V loop power source

Brand: ConST

SOLUTIE PORTABILA CALIBRARE HIDRAULICA PRESIUNE CONST

• portable gauge and transmitter calibration system that is very conveniently use on-site
• compact, easily operation, reduces calculations errors and has a 0.02% full scales accuracy
• up to 9000PSI (600 bar)
• weather-proof kitbag that can protect instruments well

Brand: ConST

POMPA PORTABILA HIDRAULICA CALIBRARE PRESIUNI -90%~ 700 BAR CONST132

• Pressure: -95%~ 40bar
• Pressure resolution: 0.1mbar (10Pa)
• Size: 315mm *198mm * 140 mm Weight:3.0 kg
• Can test big-cavity pressure gauges
• Using helicoidal-pump to easy pressurize

Brand: ConST

POMPA HIDRAULICA CALIBRARI PRESIUNI INALTE -90%~ 2500 BAR CONST186

• Pressure: -90%~ 2500 bar
• Oil media
• Durable and Minimal Maintenance
• Easy-to-use
• Extremely low leakage

Brand: ConST

POMPA PNEUMATICA CALIBRARE PRESIUNI -95%~ 40 BAR CONST117

• Pressure: -95%~ 40bar
• Pressure resolution: 0.1mbar (10Pa)
• Size: 315mm *198mm * 140 mm Weight:3.0 kg
• dual pressure source with the ability to easily adjust and stabilize
• Ideal pressure source for big cavity pressure gauge User friendly design

Brand: ConST

MANOMETRU DIGITAL DE PRECIZIE MASURA PRESIUNI CONST211

• Differential pressure: down to 0.6mbar (6mmH2O)
• Gauge pressure: up to 2500bar (37500psi)
• Long working time: 6,000 hours
• Large, easy-to-read display with 5 digit resolution
• Bar graph for quick visual and % pressure indication
• Measuring Speed : up to 10 times/s
