Precision Laboratory Frequency Counter 10 digit 6-GHz TTi TF960

• 10 MHz ..26.5 GHz bandwidth
• Measurement range from -50 dBm to +20 dBm
• Replacement solution for conventional power meter and sensor combination
• Simple USB connection to laptop or PC
• Use multiple sensors on one laptop or PC



• 1MHz to 2700MHz frequency range
• Resolution bandwidths of 1MHz, 280kHz or 15kHz
• -96dBm typical noise floor at -20dBm reference level
• Measurement in dBm or dBµV, mV or µW
• Zero span mode with AM and FM audio demodulation



• 120V or 250V, 90W, Linear, True Analog Control
• Linear regulation - for the best performance
• Ultra-compact design - uses up less space
• True Analog controls - for ease of use



• 0.001Hz to 10MHz frequency range
• 6 digits or 1mHz resolution
• 1ppm stability and 10ppm one year accuracy



• Frequency, period, pulse width, frequency ratio, duty cycle, and event counter modes
• DC to 6000MHz range, 0.001mHz resolution
• High impedance measurement up to 125 MHz
• AC or DC coupling, 1M/50Ohm selection, polarity invert
• Switchable attenuator, threshold control



• 0.03Hz to 3MHz frequency range
• Simultaneous display of frequency & amplitude
• High waveform quality at all frequencies & levels
• 2mV to 20V pk-pk from 50 Ohms or 600 Ohms



• 0.1Hz to 10MHz frequency range
• Independent control of pulse frequency, width and delay
• 50ns minimum pulse width
• Squarewave, double pulse & delayed pulse modes
• Free-run, gated and triggered modes
• 50 Ohm output: 0.1V to 10V amplitude



• 40 MHz sine
• 50 MHz square
• Dual channel independent or linked
• 100 MSa/s sample rate
• 12-bit vertical resolution



• 0.003Hz to 3MHz frequency range
• High waveform quality at all frequencies & levels
• 2mV to 20V pk-pk from 50 Ohms or 600 Ohms



• Compliance quality measurements to EN61000-3-2 and EN61000-3-3
• Measures peak or rms voltage or current, real or apparent power, power factor, phase
• Tabular/histogram of 40 harmonics
