RF Signal Generator 10 MHz..1 GHz TTi TGR1040

Code: TTi TGR1040




Datasheet PDF, 0.36 Mb

Description

  • 10 MHz to 1 GHz frequency range
  • 1 kHz setability, +/-2ppm frequency stability
  • -127 dBm to +7dBm amplitude, 0.1dB steps
  • FM modulation, internal or external
  • 80 character back-lit LCD display
  • Keyboard and rotary encoder control
  • Full remote control through RS232 or optional GPIB
