The use of hydrogen detectors is a tried-and-tested method that can accurately locate even the tiniest leaks in drinking water mains.

A hydrogen mixture is pumped into the pipe via a hydrant or domestic connection and then escapes at the leak, where it can be precisely detected at the surface. Hydrogen is the lightest and cheapest of all trace gases. A mixture of 5% hydrogen and 95% nitrogen is used. This environmentally friendly gas mixture is neither combustible, toxic nor corrosive.

Because it reacts so accurately and quickly, the HL H2 is ideally for precisely locating even the smallest of leaks. Audible and visual displays help the user to find leaks. The probe can be quickly and easily removed from its carrying pole in order to locate leaks in enclosed spaces.

Benefits:

H₂ sensor that is insensitive to other gases
Audible and visual leak indication
No maintenance
Reading memory (histogram)
No saturation, fast recovery
Can be used as hand-held sensor

Standard accessories

Scope of delivery HL H2 Set

HL receiver

PAM H2 hydrogen sensor

VK 95 cable

Headphones

System case

Receiver strap

Operating manual

Recommended options
