Digital Groove Measurement Stand 6870-150

Code: 6870-150




Datasheet PDF, 0.55 Mb

Description

Digital Groove Measurement Stand
Cod: 6870-150

  • Button function: on/off, zero, mm/inch, measuring direction change, data preset, absolute/incremental measurement
  • Vertical travel of holder: 150mm
  • Fine adjustment range: 2mm
  • CR2032 battery, automatic power off (time is adjustable)
  • Supplied with extension rods: 12.5mm (1pc), 25mm (1pc), 50mm (1pc)
  • Supplied with groove point and dust cover

Code:  6870-150
Whether magnetic:  no
Applicable holding stem:  Ø8mm
