BAUR TG 600 Audio frequency transmitter

Code: BAUR TG 600




Datasheet PDF, 0.31 Mb

Description

The TG 600 audio frequency transmitter was designed specifically for the precise location of cable faults and joints using the twist method. The display of the input and output current makes selection of the correct adjustment easier.



Features:

  • High-performance audio frequency transmitter up to 600 VA
  • Frequency of 2 or 10 kHz, quartz-stabilised (other frequencies on request)
  • Potential-free output
  • Impedance adjustment in 8 steps from 0.3 to 300 O
